Specifications
Item LED Universal Measuring Ø27 Probe
Receptor Detector: Silicon photo cell
Measurement area Ø27 mm
Acceptance angle ±2.5°
Measurement distance 30±10 mm
Display range
Luminance 0.0001 to 1000 cd/m
2
Chromaticity Displayed in 4 or 3-digit value (Can be chosen)
Luminance
Measurement range 0.0050 to 1000 cd/m
2
Accuracy
(for white)*1
0.0050 to 0.0999 cd/m
2
±4%±0.0015 cd/m
2
0.1000 to 9.999 cd/m
2
±3%±0.0010 cd/m
2
10.00 to 1000 cd/m
2
±2%±0.0010 cd/m
2
Repeatability(2 ) *1
0.0050 to 0.0999 cd/m
2
1% + 0.0010 cd/m
2
0.1000 to 0.9999 cd/m
2
0.2% + 0.0010 cd/m
2
1.000 to 1000 cd/m
2
0.1%+0.0010 cd/m
2
Chromatcity
Measurement range 0.0500 to 1000 cd/m
2
Accuracy *1
(temperature:23°±2°,
relative humidity:
(40±10)%))
0.0500 to 4.999 cd/m
2
±0.005 for white
5.000 to 19.99 cd/m
2
±0.004 for white
20.00 to 1000 cd/m
2
±0.003 for white
120 cd/m
2
±0.002 for white
(±0.004 for monochrome)*2
Repeatability(2 ) *1
0.0500 to 0.0999 cd/m
2
0.010
0.1000 to 0.1999 cd/m
2
0.004
0.2000 to 0.4999 cd/m
2
0.002
0.5000 to 1000 cd/m
2
0.001
Measurement
speed*4
xyL
V
0.0050 to 0.0999 cd/m
2
4(3.5) times/sec.
0.1000 to 1.999 cd/m
2
5(4.5) times/sec.
2.000 to 1000 cd/m
2
20(17) times/sec.
Display
Digital xyL
V
, T∆uvL
V
, RGB analyze, XYZ, uʼvʼL
V
Analog ∆x∆y∆L
V
, R/G B/G ∆G, ∆R B/R G/R
LCD 16 characters by 2 lines (with backlight)
SYNC mode NTSC, PAL, EXT, UNIV, INT
Object under measurement Vertical synchronization frequency: 40 to 200 Hz
Memory channel 100 channels
Analyzer function Standard function
Interface USB; RS-232C (38,400 bps or below)
Multi-point Measurement Max. 5 points (Use 4-Probe Expansion Board CA-B15)
Operating temperature/humidity range
Temperature: 10 to 28°C; relative humidity 70% or less with no condensation Luminance change: ±2% of reading for white
Chromaticity change ±0.002 for white, ±0.006 for monochrome from reading of Konica Minoltaʼs standard LCD *1, 120 cd/m
2
,
with 23°C 40%
Storage temperature/humidity range 0 to 28°C: relative humidity 70% or less with no condensation 28 to 40°C: relative humidity 40% or less with no condensation
Input voltage range 100-240V
AC power cord, PC Software for Color Analyzer CA-SDK, Standard Hood CA-H10
4-Probe Expansion Board CA-B15, Universal Measuring ø27 Probe CA-PU32(2 m) CA-PU35(5 m), Standard Hood CA-H10,
Standard Lens Cap CA-H11, USB cable IF-A18
, 50-60 Hz, 50 VA *6
Size/weight
Standard accessories
Optional accessories
Main body 340(W)×127(H)×216(D) mm / 3.58 kg
Probe Ø49×208 mm / 530 g
*1 The chromaticity and luminance are measured under Konica Minolta's condition (standard LCD(6500K, 9300K) is used).
*2 The luminance for monochrome is measured when the reading of luminance for white is 120 cd/m
2
*3 Measurement of flicker (JEITA method) is supported by SDK software.
*4 Measuring probe connected to probe connector P1 only, used USB(used RS-232C Baud rate: 38400 bps)
*5 Measured by Konica Minolta's PC (P3-600 MHz)
*6 " " represents alternating current available at power outlets.
The specifications and drawings given here are subject to change without prior notice.
