Getting started
RQT6035
8
Main unit
Page
1 POWER button (ê/I, POWER) . . . . . . . . . . . . . . . . . . . . . . . 16
Press to switch the unit from ON to STANDBY mode or vice versa.
In standby mode, the unit is still consuming a small amount of power.
2 Recording mode button (REC MODE) . . . . . . . . . . . . . . . . 26
3 Channel buttons (X, W, CH) . . . . . . . . . . . . . . . . . . . . . . . . . 26
4 Recording button (´, [REC]) . . . . . . . . . . . . . . . . . . . . . . . . . 26
5 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
6 Disc tray open/close button (<, OPEN/CLOSE) . . . . . . . . 22
7 Stop button (º) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 Pause button (;) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9 Play button (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
: Time slip button and roller (TIME SLIP) . . . . . . . . . . . . . . . 29
; L2 input terminals (L2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
< Disc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
= Top window button (TOP WINDOW) . . . . . . . . . . . . . . . . . . 30
> Cursor buttons (3, 4, 2, 1) . . . . . . . . . . . . . . . . . . . . . . . 19
? Enter button (ENTER) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
@ Return button (RETURN) . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
A Slow/search buttons (6, 5) . . . . . . . . . . . . . . . . . . . . . 24
B Skip buttons (:, 9) . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Control reference guide
Remote control
Page
C TV channel buttons ([TV], W, X, CH) . . . . . . . . . . . . . . . . . . 13
D TV power on/off button ([TV], POWER ê) . . . . . . . . . . . . . . 13
E Television input mode selector ([TV], TV/AV) . . . . . . . . . . . 13
F Top menu and Direct Navigator button
(TOP MENU, DIRECT NAVIGATOR) . . . . . . . . . . . . . . . 23, 56
G Joystick (3, 4, 2, 1)/Enter button (ENTER) . . . . . . . . . . 16
H Manual programming and check button
(PROG/CHECK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
I VCR Plusr button (VCR Plusr) . . . . . . . . . . . . . . . . . . . . . 43
J Time slip button (TIME SLIP) . . . . . . . . . . . . . . . . . . . . . . . . 29
K One-minute skip button (CM SKIP) . . . . . . . . . . . . . . . . . . . 32
L Manual channel adding and deleting button
(ADD/DLT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
M DVD/TV switch (DVD, TV) . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
³When selecting numbered items on this unit, be sure
to switch [DVD, TV] to “DVD”.
³When selecting channels on the television, be sure to
switch [DVD, TV] to “TV”.
N Virtual Surround Sound button (V.S.S.) . . . . . . . . . . . . . . . 39
O TV volume buttons ([TV], r, s, VOL) . . . . . . . . . . . . . . . . . 13
P Display button (DISPLAY) . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Q Menu and Play List button (MENU, PLAY LIST) . . . . . 23, 65
R On-screen display button (STATUS) . . . . . . . . . . . . . . . . . . 94
S Frame advance and frame reverse buttons
(2;, ;1, FRAME) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
T Numbered buttons (1–0, 100) . . . . . . . . . . . . . . . . . . . . . . . 23
³When selecting a title, chapter, track, program, or play list
Example: “5”: [0] ➡ [5]
Example: “15”: [1] ➡ [5]
³When selecting a page of play list scene
Example: “5”: [0] ➡ [0] ➡ [5]
Example: “15”: [0] ➡ [1] ➡ [5]
³When selecting a television channel
Example: “5”: [0] ➡ [5]
Example: “15”: [1] ➡ [5]
Example: “115”: [100] ➡ [1] ➡ [5]
U Cancel button (CANCEL) . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
V Last marker button (LAST MARKER) . . . . . . . . . . . . . . . . . 23
W Audio button (AUDIO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
X Marker write button (MARKER WRITE) . . . . . . . . . . . . . . . 36
Y Action button (ACTION) . . . . . . . . . . . . . . . . . . . . . . . . . 19, 85
Z Input select button (INPUT SELECT) . . . . . . . . . . . . . . . . . 49
Buttons such as 1 function the same
as the controls on the unit.
º Opening the front panel
Open the front panel to access other controls and input ter-
minals.
POWER
REC MODE OPEN/CLOSE
/I
REC
TOP
WINDOW
ENTER
RETURN
TV
STOP
DVD
PAUSE PLAY
T
C
E
R
I
D
CH
TV/AV
PROG / CHECK
TOP WINDOW
FRAME
SKIP
VCR Plus+
REC
TIME SLIP CM SKIP
V.S.S.
ACTION
AUDIO
ADD/DLT
REC MODE
CANCEL
INPUT
SELECT
LAST
MARKER
MARKER
WRITE
CH
123
456
789
0
SLOW/SEARCH
S TATU S
RETURN
ENTER
VOL
POWER
POWER
OPEN/CLOSE
R
O
T
A
G
I
V
A
N
T
O
P
M
E
N
U
M
E
N
U
D
I
S
P
L
A
Y
T
S
I
L
Y
A
L
P
100
TVDVD
TIME SLIP
CH
1
;<=>?@AB
32 4 65 789 :
D
E
1
F
G
H
O
6
Q
@
R
S
A
9
T
3
V
W
X
Y
Z
U
8
P
C
=
B
7
L
M
N
2
4
J
K
I
CH
FRAME
SKIP
SLOW/SEARCH
VOL
CH
!?
