1.WHAT IS INCLUDED
1 Indoor/Outdoor Night
Vision CCD Color Camera
Window
Warning Stickers
60ft 4 PIN DIN to RCA
(male) Video/Power Wire
• PowerAdapterforCamera
• 1YearWarranty
• InstructionManual
• Online/TollFreeSupport
• MountingHardware
CCD Cameras
1. Sun Shield helps prevent glare from bright lights.
2. Infrared (IR) LEDs allows the camera to see in the dark up to 15ft
away.
3. CDS Sensor turns on the infrared LEDs when it gets dark out.
4. Camera Housing made of anodized aluminum to prevent rust.
5. Camera Mount allows the camera to be desk or wall mountable.
6 . Connection to Video / Power Wire Converts to RCA.
IMPORTANT INFORMATION
Whilethiscameraisweatherproof,itisnotwaterproof.Pleasedo
notinstallitinareasthatreceivedirectrainorundereavestrough
drainingspots.DonotcuttheDCpowercableofthiscameratot
withanotherpowersource.Donotcutthevideoconnectionwire
totwithadierentvideoconnectiontype.Anyunauthorized
modicationswillvoidyourwarranty.
