6. TROUBLESHOOTING
Before contacting technical support, please use follow the troubleshooting tips below
for solutions to common problems.
No picture/signal:
- Make sure your TV/monitor is on the correct video input channel. This is NOT channel 3. Common terms for
this channel is INPUT, AV CHANNEL, LINE 1, LINE 2 and AUX. Please use your TV or VCR manual to correctly
identify this channel.
- If your camera is connected to a VCR/DVR, make sure that it is properly connected to your TV/monitor.
- Check all connections to make sure they are secure and properly connected.
- Check your power supply to ensure that the camera is powered up.
Picture is too bright:
- Make sure your camera is not aimed at direct sunlight.
- Adjust the sunshade by sliding it forwards to block out excess light.
- Make sure nothing is obstructing the CDS sensor on the camera. If the CDS sensor is blocked, night vision
mode will be active and may produce extra light in your camera’s picture.
- Move your camera to another location.
Picture is too dark:
- If using at night, make sure your camera’s subject is no more than 15ft away (may vary based on amount
of ambient light available).
- If using during the day, your camera may not be getting enough light. Adjust the sunshade by sliding it
backwards to let in more light.
- Check the brightness and contrast settings on your TV/monitor
- If your camera is connected to a VCR/DVR, check the brightness and contrast settings on the VCR/DVR
- Move your camera to another location.
Night Vision is
not working:
- The night vision turns on automatically when light levels drop. Try the camera in a pitch black setting. The
area that it is in may have too much light and may not activate the sensor.
OUTDOOR CAMERA
Camera Type .................................................................................Bullet
Image Sensor ................................................................1/4" Color CCD
Resolution ......................................................................... 420 TV Lines
Outdoor Use .....................................................................................Yes
IP Rating ........................................................................................IP65
Focal Length...............................................................................3.6mm
Focus Type .....................................................................................Fixed
Night Vision ......................................................................................Yes
Number of IR LEDs (and Range) .......................................12, up to 15ft
IR LED Control ...................................................Automatic (CDS Sensor)
Min. Illumination .......................................................................... 0 lux
IR Wavelength ............................................................................850nm
Video Output ................60ft 4 PIN DIN to RCA (male) Video/Power Wire
TV System .....................................................................................NTSC
Microphone .......................................................................................No
Motion Detection ..............................................................................No
Viewing Angle ..................................................................... 60 Degrees
Electronic Shutter .................................................1/60 ~ 1/100000 sec
7. SPECIFICATIONS
BLC ....................................................................................................No
AGC .......................................................................................Automatic
ELC ........................................................................................Automatic
Line Lock ...........................................................................................No
Iris Control .........................................................................................No
White Balance .......................................................................Automatic
Sun Shield ........................................................................................Yes
IR Cut Filter........................................................................................No
Housing Material ...................................................Anodized Aluminum
Housing Color ................................................................Midnight Black
Signal/Noise Ratio ......................................................................>48dB
Camera Bracket ................................................................................Yes
Operating Temperature .................................................. -14°F ~ 122°F
Operating Humidity .......................................................................98%
Camera Power Input .......................................................DC 12V 300mA
Power Adapter Input ............................................................120V 60Hz
LED Power Indicator ..........................................................................No
Dimensions .................................................................. 5.5" x 5" x2.44"
Weight .................................................................. 0.85lbs (with stand)
