Playback
Still-picture playback
Normal playback
1
Set the power switch to ON, and insert the
cassette tape.
2
Press the PLAY button to start playback.
When 8 cameras are being used, the 8 camera
numbers appear on the camera number display of
the display tube, and the number of the camera
whose pictures are being played back is enclosed
in a square.
4
To stop the playback, press the STOP button.
<
21
21
65
∫;
34
34
34
H
H
2 41
3
1
Set the power switch to ON, and insert the
cassette tape.
2
Press the PLAY button to start playback.
3
Press the PAUSE STILL button.
The unit is now set to the still-picture playback
mode.
(When the frame advance button is pressed in the
still-picture playback mode, the tape is played back
one frame at a time.)
4
Press the PLAY button again to return to normal
playback.
5
To stop the playback, press the STOP button.
<
21
21
65
∫;
34
34
34
H
H
2•4
5
31
CAMERA
1
7
2
8
5643
3
Press the CAMERA buttons to set the playback
camera.
<Note>
When video noise in blocks interferes with playback,
press the (+) or (–) tracking button until the noise is
eliminated.
<Note>
If a switch is made to cameras No.13 to 16 when a
tape which was frame-recorded using cameras No.13
to 16 is being played back in the still-picture playback
mode, blue background signals will be output.
