ASVC Kn S615 b Reading of the current data of a DIO board
Description: The current status of the named DIO board will be read.
Syntax: b: Board number (1, 2, 3 ,4; not SLOT-ID);
for b = 0 the data of all available DIO's will be sent
Response: ASVC 0 IIIIIIII OOOOOOOO OOOOOOOO OOOOOOOO RLLL
I1...8 Status of the digital input pins 1...8
O1...24 Status of the digital output pins 1...24
R Retrigger error
L1...3 Overload group 1...3
SSVC Kx S617 n s [n s] Setup of the external switch variable DIGEXTSWITCH
Description: The outputs of a DIO board can be assigned to the single bits of the variable
DIGEXTSWITCH. For the platform the lowest 8 bits of this variable are available. With the command
"SSVC" each switch can be set. This on the other hand may cause a direct switch of an assigned
digital output.
Syntax: n: Switch number
s = Status (0 = OFF; 1 = ON)
x: If the channel number will be K0, the variable DIGEXTSWITCH will be called of the
module containing the local SIO
(platform SIO → control module, MLT SIO → analyzer module).
The parameters "n s" can be repeated up to seven times for the platform.
Examples: SSVC K0 S617 1 1 2 0 3 1 Set external switch 1 to HIGH
Set external switch 2 to LOW
Set external switch 3 to HIGH
Supplement - 6
AK
90003752(1) [AK-Commands] 10/98
