186
Chapter 5: Reference
The Trigger Tab
You can use the following types of events in these trigger functions:
patterns, ranges, flags, and Wait for arm in (see “To cross-trigger with
another instrument” on page 112).
These trigger functions provide trigger actions. You cannot modify
these actions or insert any other actions.
Only one of these trigger functions can be used at a time; in other
words, they cannot be sequenced to provide more sophisticated
triggering.
• Find pattern
Trigger when the specified pattern occurs.
• Find 2 patterns in immediate sequence
Trigger when the second specified pattern occurs in the next sample after
a sample in which the first specified pattern occurs.
• Find 3 patterns in immediate sequence
Trigger when all three specified patterns occur in the specified order. The
occurrence of each pattern must be in contiguous samples.
• Find 4 patterns in immediate sequence
Trigger when all four specified patterns occur in the specified order. The
occurrence of each pattern must be in contiguous samples.
• Find 2 patterns in eventual sequence
Trigger when the second specified pattern occurs, eventually, after the
first specified pattern has already occurred.
• Find 3 patterns in eventual sequence
Trigger when all three specified patterns occur, eventually, in the specified
order.
• Find 4 patterns in eventual sequence
Trigger when all four specified patterns occur, eventually, in the specified
order.
• Run until user stop
Sets up to never trigger. You must select the stop button to view the
