226
Chapter 5: Reference
Error Messages
fetch at an address that is not properly aligned, the trigger will never be
found.
• Trigger set incorrectly
Some strategies you can use when verifying or debugging trigger
sequence levels are:
• Look at the run status message line or open the Run Status window. It will
tell you what level of the sequence the logic analyzer is in.
• Stop the measurement and look at the data that was captured. This is
particularly useful when you use store qualifiers to store "no states" (or
only the states you are interested in) and the branches taken are stored.
• Save the trigger setup, then simplify it to see what part of the sequence
does get captured. When you learn what needs to be changed, you can
recall the original trigger setup and make changes to it.
See Also “To specify default storing” on page 76
“To save a trigger setup” on page 90
