2. OUTPUT DATA (Instrument
→ →
→ →
→PC
)
1. Measurement Data
Measurement data is output by the CA-100Plus according to the present display mode. However, the format of the
output data will be slightly different from the format of the displayed data.
When the optional 4-Probe Expansion Board CA-B04 is used
The probe number for which data will be output should be selected using the command:
“ O probe number ”
In the following, “_” indicates a space.
● Display mode: xyLv
Format:
probe number _ x value ; y value ; Lv value delimiter
Probe number: Value from 1 to 5; probe number for which data is being output. In example, data is being output for
probe connector P1.
x value, y value: First three decimal places output. In example, x = 0.310 and y = 0.330. (When 4-digit display is
set: 4 characters are output)
Lv value: Up to four characters output; if value consists of fewer than four characters, value will be preceded by the
required number of spaces. In example, Lv = 150.
•
Example: P1 _ 310; 330; _ 150 delimiter
● Display mode: T∆uvLv
Format:
P probe number _ T value ; ∆uv value ; Lv value delimiter
Probe number: Value from 1 to 5; probe number for which data is being output. In example, data is being output for
probe connector P1.
T value: Up to five characters output; if value consists of fewer than five characters, value will be preceded by the
required number of spaces. In example, T = 6500.
∆uv value: First three decimal places output; preceded by a space if positive or “-” if negative. In example, ∆uv =
+ 0.005. (When 4-digit display is set: 4 characters are output)
Lv value: Up to four characters output; if value consists of fewer than four characters, value will be preceded by the
required number of spaces. In example, Lv = 150. (When 4-digit display is set: 5 characters are output)
•
Example: P1 _ _ 6500; _ 005; _ 150 delimiter
● Display mode: Analyzer (RBG)
Analyzer (RBG) display mode is available only with an optional Analyzer Card.
Format:
P probe number _ R value ; B value ; G value delimiter
Probe number: Value from 1 to 5; probe number for which data is being output. In example, data is being output for
probe connector P1.
R value, B value, G value: Up to five characters output; if value consists of fewer than five characters, value will be
preceded by the required number of spaces. In example, R = 101, B = 99.0, and G = 114.
•
Example: P1 _ _ _ 101; _ 99.0 _ _ 114 delimiter
When the optional 4-Probe Expansion Board CA-B04 is used
Data output for more than one probe number can be selected if desired. If more than one probe number is selected,
data will be output consecutively for all selected probe numbers in numerical order.
Format:
P probe number _ measurement data* delimiter
P probe number _ measurement data* delimiter
.
.
.
.
P probe number _ measurement data* delimiter
∗ Measurement data is output ac-
cording to the format above for
the selected display mode.
