ALMMSG elements
L5K Item Description
alarm_type For an analog alarm type.
Specify For
HH high-high alarm
H high alarm
L low alarm
LL low-low alarm
POS rate-of-change positive alarm
NEG rate-of change negative alarm
Specify AM for a digital alarm.
language
Languages: EN-US (United States English), DE (Germany German), ES (Spain Spanish), FR
(France French), IT (Italian), PT (Brazil Portuguese), JA (Japanese), KO (Korean), ZH
(Chinese).
message_text Alarm message.
Enclose the message in double quotes (" "). This is a unicode string.
Message tag structure is explained in these pages.
L5X message structure
In an .L5X file, message attributes are in the Data element.
<Data Format="Message">
<MessageParameters [Message_Attributes]/>
</Data>
L5K MESSAGE structure
In an .L5K file, message attributes are in the tag statement.
<tag_name> : <type>
[(Message_Attributes)];
MESSAGE tag
