Data Type Decorated Data Export Format
Array Structure Data Type Example: an array of 3 TIMER tags
<Data Format="Decorated">
<Array DataType="TIMER" Dimensions="3">
<Element Index="[0]">
<Structure DataType="TIMER">
<DataValueMember Name="PRE" DataType="DINT" Radix="Decimal"
Value="1"/>
<DataValueMember Name="ACC" DataType="DINT" Radix="Decimal"
Value="5"/>
<DataValueMember Name="EN" DataType="BOOL" Value="0"/>
<DataValueMember Name="TT" DataType="BOOL" Value="0"/>
<DataValueMember Name="DN" DataType="BOOL" Value="0"/>
</Structure>
</Element>
<Element Index="[1]">
<Structure DataType="TIMER">
<DataValueMember Name="PRE" DataType="DINT" Radix="Decimal"
Value="2"/>
<DataValueMember Name="ACC" DataType="DINT" Radix="Decimal"
Value="7"/>
<DataValueMember Name="EN" DataType="BOOL" Value="0"/>
<DataValueMember Name="TT" DataType="BOOL" Value="0"/>
<DataValueMember Name="DN" DataType="BOOL" Value="0"/>
</Structure>
</Element>
<Element Index="[2]">
<Structure DataType="TIMER">
<DataValueMember Name="PRE" DataType="DINT" Radix="Decimal"
Value="5"/>
<DataValueMember Name="ACC" DataType="DINT" Radix="Decimal"
Value="9"/>
<DataValueMember Name="EN" DataType="BOOL" Value="0"/>
<DataValueMember Name="TT" DataType="BOOL" Value="0"/>
<DataValueMember Name="DN" DataType="BOOL" Value="0"/>
</Structure>
</Element>
</Array>
</Data>
Tip:
If the decorated data for a tag exceeds 16 KB, the decorated data format will not be exported. In
this case, the raw data format will preserve the data values of the tag.
