Chapter 9 Define a function block diagram routine
172 Rockwell Automation Publication 1756-RM084S-EN-P - March 2015
L5X Item L5K Item Identifies
FromParam FromParameter The pin on the source drawing element.
For: Type:
Blocks Parameter name
Irefs In
Icons In
ToID ToElementID The destination drawing element.
Type an unsigned, 32-bit integer.
ToParam ToParameter The pin on the destination drawing element.
For: Type:
Blocks Parameter name
Orefs Out
Ocons Out
Wire guidelines
Use these wire guidelines:
• Wires that are not correctly specified are not imported.
• A feedback wire follows the same format as a wire. Just connect the Source
and Destination elements to form a feedback wire.
The text box blocks in an SFC routine hold descriptions about SFC components.
L5X TextBox structure
<TextBox [TextBoxAttributes]>
<![CDATA[ text ]] >
</TextBox>
L5K TEXTBOX structure
TEXT_BOX (Text_Box_Attributes,
Text := <"text">)
END_TEXT_BOX
Text boxes
