Attribute Description
LocalTag Specify the tag name of the element in the local device.
Specify LocalTag := text
RemoteElement Specify the tag name of the element in the remote device.
Specify RemoteElement := value
DHPlusSourceLink If the communication method uses DH+, specify the source link (0...65,535).
Specify DHPlusSourceLink := value
DHPlusDestinationLink If the communication method uses DH+, specify the destination link (0...65,535).
Specify DHPlusDestinationLink := value
DHPlusDestinationNode If the communication method uses DH+, specify the destination node number (0...63 octal).
Specify DHPlusDestinationNode := value
DHPlusChannel
If the communication method uses DH+, specify the DH+ channel. Type A or B.
Specify DHPlusChannel := letter
CacheConnections
If the message is to cache connections, type TRUE. If the message is not to cache connections, type FALSE.
Specify CacheConnections := text
ServiceCode If the message type is CIP Generic, specify the service code (0...255 hexadecimal).
Specify ServiceCode := #16value
ObjectType If the message type is CIP Generic, specify the object type (0...65,535 hexadecimal).
Specify ObjectType := 16#value
TargetObject If the message type is CIP Generic, specify the target object (0...65,535 decimal).
Specify TargetObject := value
AttributeNumber If the message type is CIP Generic, specify the attribute number (0...65,535 hexadecimal).
Specify AttributeNumber := 16#value
DestinationTag Specify the tag name of the destination element.
Specify DestinationTag := text
Version 2.0 (major revision 2, minor revision 0) of the import/export feature
included with Logix Designer, version 9.0 includes these major enhancements:
• Replaced the AXIS tag with AXIS_CONSUMED, AXIS_SERVO,
AXIS_SERVO_DRIVE, and AXIS_VIRTUAL tags.
• For any attribute that you can specify a not applicable state, type <NA>,
rather than NA.
• Revised manual that includes a description and example of the STRING
data type.
Important:
Version 9 of Logix Designer only supports ControlLogix processors.
Import/Export version 2.0
Logix Designer version 9
