Import and export files Chapter 1
Rockwell Automation Publication 1756-RM084S-EN-P - March 2015 25
3. In the File name box, type the name of the file.
4. From the Save as type list, click .L5X file format and click Save.
Important: The application automatically saves any unsaved edits when you click OK.
Import controller information from a saved XML file that has an .L5X extension
and is a full controller export. This lets you use any editor to create a project.
Do these steps to import a controller .L5X XML file into a project.
1. In the Logix Designer application, click File > Open.
The Open Project dialog box opens.
2. In the File name box, select the .L5X controller file you want to import and
click Open.
Import an .L5X XML File
