Define a function block diagram routine Chapter 9
Rockwell Automation Publication 1756-RM084S-EN-P - March 2015 181
Instruction Default Operand and VisiblePins formats (components within the Block structure)
OSRI Operand := OSRI_01,
VisiblePins := "InputBit, OutputBit")
PI Operand := PI_01,
VisiblePins := "In, Out")
PIDE Operand := PIDE_01,
VisiblePins := "PV, SPProg, SPCascade, RatioProg, CVProg, FF, HandFB, ProgProgReq, ProgOperReq, ProgCasRatReq, ProgAutoReq, ProgManuaReq,
ProgOverrideReq, ProgHandReq, CVEU, SP, PVHHAlarm, PVHAlarm, PVLAlarm, PVLLAlarm, PVROCPosAlarm, PVROCNegAlarm, DevHHAlarm,
DevHAlarm, DevLAlarm, DevLLAlarm, ProgOper, CasRat, Auto, Manual, Override, Hand")
PMUL Operand := PMUL_01,
VisiblePins := "In, Multipler, Out")
POSP Operand := POSP_01,
VisiblePins := "SP, Position, OpenedFB, ClosedFB, OpenOut, CloseOut")
RAD Operand := RAD_01,
VisiblePins := "Source, Dest")
RESD Operand := RESD_01,
VisiblePins := "Set, Reset, Out, OutNot")
RLIM Operand := RLIM_01,
VisiblePins := "In, ByPass, Out")
RMPS Operand := RMPS_01,
VisiblePins := "PV, CurrentSegProg, OutProg, SoakTimeProg, ProgProgReq, ProgOperReq, ProgAutoReq, ProgManualReq, ProgHoldReq, Out,
CurrentSeg, SoakTimeLeft, GuarRampOn, GuarSoakOn, ProgOper, Auto, Manual, Hold",
RampValue := array_name,
SoakValue := array_name,
SoakTime := array_name)
RTOR Operand := RTOR_01,
VisiblePins := TimerEnable, PRE, Reset, ACC, DN")
SCL Operand := SCL_01,
VisiblePins := "In, Out")
SCRV Operand := SCRV_01,
VisiblePins := "In, Out")
SEL Operand := SEL_01,
VisiblePins := "In1, In2, SelectorIn, Out")
SETD Operand := SETD_01,
VisiblePins := "Set, Reset, Out, OutNot")
SIN Operand := SIN_01,
VisiblePins := SIN(source,destination);
SNEG Operand := SNEG_01,
VisiblePins := "In, NegateEnable, Out")
SOC Operand := SOC_01,
VisiblePins := "In, Out")
SQR Operand := SQR_01,
VisiblePins := "Source, Dest")
SRTP Operand := SRTP_01,
VisiblePins := "In, HeatOut, CoolOut, HeatTimePercent, CoolTimePercent")
