Chapter 8 Define a ladder logic routine
156 Rockwell Automation Publication 1756-RM084S-EN-P - March 2015
Instruction Neutral Text Format
OTU OTU(data_bit);
PATT PATT(phase_name,result);
PCLF PCLF(phase_name);
PCMD PCMD(phase_name,command,result);
PDET PDET(phase_name);
PFL PFL(source);
PID PID(PID,process_variable,tieback,control_variable,pid_master_loop,
inhold_bit,inhold_value);
POVR POVR(phase_name,command,result);
PPD PPD();
PRNP PRNP();
PSC PSC();
PXRQ PXRQ(phase_instruction,external_request,data_value);
RAD RAD(source,destination);
RES RES(structure);
RET RET(return_1,...return_n);
RIN RIN(rin_tag,reset_type,channel_A,channel_B,circuit_reset,fault_reset);
ROUT ROUT(rout_tag,feedback_type,enable,feedback_1,feedback_2,fault_reset);
RTO RTO(timer,preset,accum);
RTOS RTOS(source,destination)
SBR SBR(routine_name,input_1,...input_n);
SFP SFP(SFC_routine_name,target_state);
SFR SFR(SFC_routine_name,step_name);
SIN SIN(source,destination);
SIZE SIZE(souce,dimension_to_vary,size);
SMAT SMAT(smat_tag,restart_type,short_circuit_detect_delay_time,channel_A,
channel_B,input_status,reset);
SQI SQI(array,mask,source,control,length,position);
SQL SQL(array,source,control,length,position);
SQO SQO(array,mask,destination,control,length,position);
SQR SQR(source,destination);
SRT SRT(array,dim_to_vary,control,length,position);
SSV SSV(class_name,instance_name,attribute_name,source);
STD STD(array,dim_to_vary,destination,control,length,position);
STOD STOD(source,destination)
STOR STOR(source,destination)
SUB SUB(source_A,source_B,destination);
SWPB SWPB(source,order_mode,destination);
TAN TAN(source,destination);
