Encoded data attributes
L5X Item L5K Item Description
type type The type of data encoded.
In L5K, specify ADD_ON_INSTRUCTION_DEFINITION
In L5X, specify AddOnInstructionDefinition
name name The name of the protected Add-On Instruction.
SignatureID SignatureID 32-bit value based upon the current configuration of the
Add-On-Instruction.
SignatureTimestamp SignatureTimestamp The time and date that the Add-On-Instruction was sealed.
SafetySignatureID SafetySignatureID Only applies to Safety Add-On-Instructions. Additional safety ID
calculated online in the safety system.
N/A other_attributes Attributes of the Add-On Instruction that are not protected
during export.
N/A encoded_data The protected portion of the Add-On Instruction.
Important:
When the Add-On Instruction is source-protected, the encoded_data information is encrypted. If you
modify this encrypted information, you cannot re-import the Add-On Instruction.
