Chapter 9 Define a function block diagram routine
182 Rockwell Automation Publication 1756-RM084S-EN-P - March 2015
Instruction Default Operand and VisiblePins formats (components within the Block structure)
SSUM Operand := SSUM_01,
VisiblePins := "In1, Select1, In2, Select2, In3, Select3, In4, Select4, Out")
SUB Operand := SUB_01,
VisiblePins := "SourceA, SourceB, Dest")
TAN Operand := TAN_01,
VisiblePins := "Source, Dest")
TOD Operand := TOD_01,
VisiblePins := "Source, Dest")
TOFR Operand := TOFR_01,
VisiblePins := "TimerEnable, PRE, Reset, ACC, DN")
TONR Operand := TONR_01,
VisiblePins := "TimerEnable, PRE, Reset, ACC, DN")
TOT Operand := TOT_01,
VisiblePins := "In, ProgProgReq, ProgOperReq, ProgStartReq, ProgStopReq, ProgResetReq, Total, OldTotal, ProgOper, RunStop, ProgResetDone,
TargetFlag, TargetDev1Flag, TargetDev2Flag")
TRN Operand := TRN_01,
VisiblePins := "Source, Dest")
UPDN Operand := UPDN_01,
VisiblePins := "InPlus, InMinus, Out")
XOR Operand := XOR_01,
VisiblePins := "SourceA, SourceB, Dest")
XPY Operand := XPY_01,
VisiblePins := "SourceA, SourceB, Dest")
