Define a module component Chapter 4
Rockwell Automation Publication 1756-RM084S-EN-P - March 2015 73
Attribute Description
SafetyNetwork If the module is in a safety controller system, specify the 6-byte hexadecimal number of the safety network.
SafetyEnabled
A flag only in modules that can be configured as safety or standard. Type true if the module is a safety module.
RSNetWorxFileName L5K only. Specify the file name of an associated RSNetWorx project file.
Inhibited
L5X only. If the module is inhibited, type true. If the module is not inhibited, type false.
MajorFault
L5X only. Specify if the controller generates a major fault if the connection to the module is lost in run mode (true or false).
ConfigSize L5X only. This attribute is on the <ConfigTag> or <ConfigData> element. Specify the size of the Config Tag or Config Data.
Id
L5X only. This attribute is on the <Port> element. It uniquely identifies the port.
Address
L5X only. This attribute is on the <Port> element. Specify the node number, slot number, or IP address/host name.
Type
L5X only. This attribute is on the <Port> element. Defines the type of the module
Upstream
L5X only. This attribute is on the <Port> element. It is determined by the I/O topology of the module. Specify true for Upstream or
false for downstream.
NATActualAddress The IP address of a safety I/O module or controller specified by the user as the actual address on the network of the module.
For L5X, this attribute is on the <Port> element.
ConnectorOffset
L5X only. This attribute is on the <Port> element.
Width
L5X only. This attribute is on the <Port> element.
Size L5X only. This attribute is on the <Bus> element. For a sizable chassis, specify the chassis size.
In L5K, this attribute is the ChassisSize attribute on the MODULE.
Baud L5X only. This attribute is on the <Bus> element. Specify the baud rate (57.6, 115.2, or 230.4).
In L5K, this attribute is the ChABaud or ChBBaud attribute on the MODULE.
ShutdownParentOnFault Indicates the parent device is shut down when this module faults.
DrivesADCMode Sets or clears the Drives ADC mode bit.
Setting to true on a non-ADC causes the drive to fail.
DrivesADCEnabled Indicates that Automatic Device Configuration is enabled for this device.
Can be set true only when the DrivesADCMode is set true.
UserDefinedCatalogNumber Used to persist the Catalog Number for drive peripherals.
You do not have to modify this value.
