Chapter 2 Define a controller component

50 Rockwell Automation Publication 1756-RM084S-EN-P - March 2015

</ParameterConnections>

<CommPorts>

[commport]

</CommPorts>

<CST [attribute_list] />

<WallClockTime [attribute_list] />

<Trends>

[trend]

</Trends>

<QuickWatchLists>s

[watch_list]

</QuickWatchLists>

< InternetProtocol [Internet_Protocol_Attributes] />

<EthernetPorts>

<EthernetPort [Ethernet_Port_Attributes] />

<EthernetPort [Ethernet_Port_Attributes] />

</EthernetPorts>

<EthernetNetwork [Ethernet_Network_Attributes] />

</Controller>

Tip:

The L5X controller structure must be contained within an RSLogix5000Content root element begin tag

(<RSLogix5000Content>) and end tag (</RSLogix5000Content>). See the .L5X File Structure on page 35 in Chapter

1 for more information.

L5K CONTROLLER structure

CONTROLLER <controller_name> [(Description := "text",

Controller_Attributes)]

[<DATATYPE declaration>]

[<MODULE declaration>]

[<ADD_ON_INSTRUCTION_DEFINITION declaration]

TAG

[<tag declarations>]

END_TAG

[<PROGRAM declaration>]

[<TASK declaration>]

[PARAMETER_CONNECTION declaration]

[<TREND declaration>]

[<QUICK_WATCH declaration>]

[<CONFIG controller objects declaration>]

END_CONTROLLER
