Chapter 9 Define a function block diagram routine
180 Rockwell Automation Publication 1756-RM084S-EN-P - March 2015
Instruction Default Operand and VisiblePins formats (components within the Block structure)
LES Operand := LES_01,
VisiblePins := "SourceA, SourceB")
LIM Operand := LIM_01,
VisiblePins := "LowLlimit, Test, HighLimit")
LN Operand := LN_01,
VisiblePins := "Source, Dest")
LOG Operand := LOG_01,
VisiblePins := "Source, Dest")
LPF Operand := LPF_01,
VisiblePins := "In, Out")
MAVE Operand := MAVE_01,
VisiblePins := "In, Out",
Storage := array_name,
Weight := array_name)
MAXC Operand := MAXC_01,
VisiblePins := "In, Reset, ResetValue, Out")
MEQ Operand := MEQ_01,
VisiblePins := "Source, Mask, Compare")
MINC Operand := MINC_01,
VisiblePins := "In, Reset, ResetValue, Out")
MOD Operand := MOD_01,
VisiblePins := "SourceA, SourceB, Dest")
MSTD Operand := MSTD_01,
VisiblePins := "In, SampleEnable, Out",
Storage := array_name)
MUL Operand := MUL_01,
VisiblePins := "SourceA, SourceB, Dest")
MUX Operand := MUX_01,
VisiblePins := "In1, In2, In3, In4, In5, In6, In7, In8, Selector, Out")
MVMT Operand := MVMT_01,
VisiblePins := "Source, Mask, Target, Dest")
NEG Operand := NEG_01,
VisiblePins := "Source, Dest")
NEQ Operand := NEQ_01,
VisiblePins := "SourceA, SourceB")
NOT Operand := NOT_01,
VisiblePins := "Source, Dest")
NTCH Operand := NTCH_01,
VisiblePins := "In, Out")
OR Operand := OR_01,
VisiblePins := "SourceA, SourceB, Dest")
OSFI Operand := OSFI_01,
VisiblePins := "InputBit, OutputBit")
