D-160 Owner's manual (SETUP mode)
147
Delete all Tempo Setting at once
If you proceed with "Delete all Time Signature Setting at once" as described in the previous
section, the D-160 will erase all the tempo settings as well as the time signature settings.
* Refer to the "Delete all Time Signature Setting at once" section for details.
2-4. Program Title Setting ("Title Edit PGM?")
This mode gives a name to the individual program (maximum of 99 programs).
Also, the registered name can be edited.
Choose a required program before you enter to the SETUP mode if you are newly giving
a title or editing a title.
1. Press the DISP SEL key and choose the flashing SETUP mode on the display. Then, press the
EXECUTE/YES key.
The SETUP display stops flashing.
2. With the JOG dial, choose "TitleEdit PGM?".
The "?" display will start flashing.
3. Press the EXECUTE/YES key.
The D-160 will enter the second step menu of "TitleEdit PGM?" and show the current program
title. In the case of the initial setting, the display will show "#0001" with "#" flashing.
The flashing digit allows you to enter a letter. The available letters are a maximum of 16 digits of
alphabet or numbers. The D-160 handles ASCII code.
44.1kHz
SETUP
91011121314151687654321
42
OL
0
30
24
18
12
9
6
3
∞
_
4. Use the JOG dial to enter a required letter. Then, use either the HOLD/> key or SHUTTLE dial to
move the flashing digit.
5. Press the EXECUTE/YES key after you have entered the required title.
The title will now be registered and the display will then go back to the normal time base display
as before you entered SETUP mode.
2-5. Program Delete ("Delete PGM?")
This mode allows you to delete program data which you no longer need.
You can delete the currently chosen program to obtain more recording space.
<Notes>
* The D-160 automatically renumbers the remained programs after deleting a program between
the other two programs. For example, if you delete program number 2 of program numbers
1,2,3 and 4, number 3 will automatically become the new program number 2 and number
4 will become the new program number 3. Then, the D-160 will end up having three programs
rather than four.
* If you try to delete program number 1 when there is only one program available, the D-160
will set up a new blank program 1 after erasing the current program 1 data.
* This program delete mode does not have an "UNDO" function.
* The Program delete mode will not work if the "Rec Protect ?" mode is set to On. The D-160
will display "Disable REC!" as a warning message and go back to the normal time base
display the same as before you entered SETUP mode.
