D-160 Owner's manual (SETUP mode)
164
2-21. Current Drive Setting (“Drive Sel.?”)
The “Current Drive” here means the medium drive device, either the internal IDE or SCSI,
to be used in real time recording or playing back.
For example, you need to set this mode to “SCSI” if you want to directly record data on to
the external SCSI device at real time or enter a title in the song number/back up number
on the SCSI device.
This mode allows you to choose the current drive from either the internal IDE hard disk
which is installed in the D-160, or a SCSI device which is externally connected.
If you choose the SCSI device whose medium has not been formatted, the D-160 will
automatically recognize it as an “unformatted medium” and move on to the “Disk Format?”
menu in the SETUP mode.
Then, after completing the format process, the “SCSI” will be chosen as the current drive.
* Initial setting : IDE (internal hard disk)
* Available setting : IDE, SCSI
* The setting will go back to “IDE” when you turn the power to off.
1. Press the DISP SEL key and choose the flashing SETUP mode on the display. Then, press the
EXECUTE/YES key.
The SETUP display will stop flashing.
2. With the JOG dial, choose “Drive Sel.?”.
The “?” display will start flashing. The display will also show the current setting.
In the case of the initial setting, it will show “IDE”.
3. Press the EXECUTE/YES key.
The current setting will start flashing which indicates it is ready to change setting.
44.1kHz
SETUP
91011121314151687654321
42
OL
0
30
24
18
12
9
6
3
∞
_
4. With the JOG dial, choose either “IDE” or “SCSI” you want.
5. Press EXECUTE/YES key after choosing the setting you want.
The display will go back to the display of item 2.
* Press either the STOP button or EXIT/NO key to return from the second step menu to the
first or to quit SETUP mode. The menu will go backwards each time you press either key so
that you can correct the setting, choose some other SETUP mode or eventually return to
the normal time base display.
<Notes>
* When you are to choose “SCSI” as the current drive, the display will show “Initializing ....”
then, “No SCSI Device!” and go back to the display of Item 2 if the power of the externally
connected SCSI device is not turned ON, or if it is not connected properly. Similarly, the
display will show “No Disk!” if the SCSI device does not have a medium inserted correctly.
* To eject the medium from the SCSI device, press the EXIT/NO key while holding down the
STOP button with the normal time base display.
