(E) Closed correctly
(F) Not closed correctly (the cover is tilted)
Note
If the Ink Cartridge Locking Cover is not closed correctly, push down the Ink Cartridge
Locking Cover until it clicks.
Important
The machine cannot print unless both the Color and Black FINE Cartridges are installed. Be
sure to install both the FINE Cartridges.
6.
Lift the Scanning Unit (Cover) slightly to set the Scanning Unit Support back to its
original position, and gently close the Scanning Unit (Cover).
If you replaced the FINE Cartridge while printing, the machine resumes printing automatically.
Caution
When setting the Scanning Unit Support back to its original position, be sure to hold the
Scanning Unit (Cover) firmly, and be careful not to get your fingers caught.
Note
If the
Alarm
lamp lights or flashes orange after the Scanning Unit (Cover) is closed, refer to
the "
Troubleshooting
" in the on-screen manual:
A
dvanced Guide
.
When you start printing after replacing the FINE Cartridge, the machine starts cleaning the Print
Head automatically. Do not perform any other operations until the machine completes the
cleaning of the Print Head.
If ruled lines are printed with misaligned or the print head position is misaligned, adjust the print
head position.
See
A
ligning the Print Head
.
Page top
Page 82 of 628 pagesReplacing Procedure
