6
PROGRAMMING
6.2 Using Programs in Normal System Configuration
6 - 4
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
PROCEDURES AND
SETTINGS BEFORE
SYSTEM OPERATION
5
UTILITY PACKAGE
(GX CONFIGURATOR-TI)
6
PROGRAMMING
7
ONLINE MODULE
CHANGE
8
TROUBLESHOOTING
6.2 Using Programs in Normal System Configuration
This section describes program examples based on the following system configuration
and conditions.
(1) System configuration
(2) Setting conditions for the intelligent function module switch setting
Table 6.1 Setting conditions for the intelligent function module switch setting
Channel
RTD
(Measurement range)
Offset/gain setting
CH1
Pt100
(-200 to 850 )
Factory default settingCH2
CH3
CH4
to
CH8
Not used
CH1 RTD
CH2 RTD
CH3 RTD
QY10 (Y20 to Y2F)
QCPU
QX10 (X10 to X1F)
Q68RD3-G (X/Y0 to X/YF)
