6.2.2 Program example when utility package is used
(1) List of devices
Table 6.2 List of devices
Device Function
D0 Device that Conversion completion flag is written by auto refresh
D1 Device that CH1 Measured temperature value is written by auto refresh
D2 Device that CH2 Measured temperature value is written by auto refresh
D3 Device that CH3 Measured temperature value is written by auto refresh
D4 Device that Error code is written by auto refresh
D5 Device that Warning output flag (Process alarm) is written by auto refresh
D6 Device that Warning output flag (Rate alarm) is written by auto refresh
D7 Device that Disconnection detection flag is written by auto refresh
D11 CH1 Measured temperature value
D12 CH2 Measured temperature value
D13 CH3 Measured temperature value
X0 Module ready
Q68RD3-G (X/Y0 to X/YF)
XC Disconnection detection signal
XF Error flag
YF Error clear request
X10
Device that user turns ON to start reading
measured temperature values
QX10 (X10 to X1F)
X11
Device that user turns ON to reset a
disconnection detection state
X12
Device that user turns ON to reset an
error
Y20 to Y2B Error code display (BCD 3 digits) QY10 (Y20 to Y2F)
