Emerson Process Management GmbH & Co. OHG9-6
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
04/2010
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Service.Measurement.AbsMinRange2
6325…
6326
9163 Float R/W absolute minimum range of comp2
Service.Measurement.AbsMinRange3
6329…
6330
9165 Float R/W absolute minimum range of comp3
Service.Measurement.AbsMinRange4
6333…
6334
9167 Float R/W absolute minimum range of comp4
Service.Measurement.AbsMinRange5
6337…
6338
9169 Float R/W absolute minimum range of comp5
Service.Measurement.Compensation.Pfact-
Coeffs1
6541…
6548
9271…
9274
Float R/W
polynom coeffs for pressure factor of
comp1
Service.Measurement.Compensation.Pfact-
Coeffs2
6549…
6556
9275…
9278
Float R/W
polynom coeffs for pressure factor of
comp2
Service.Measurement.Compensation.Pfact-
Coeffs3
6557…
6564
9279…
9282
Float R/W
polynom coeffs for pressure factor of
comp3
Service.Measurement.Compensation.Pfact-
Coeffs4
6565…
6572
9283…
9286
Float R/W
polynom coeffs for pressure factor of
comp4
Service.Measurement.Compensation.Pfact-
Coeffs5
6573…
6580
9287…
9290
Float R/W
polynom coeffs for pressure factor of
comp5
Service.Measurement.Compensation.PfactE-
nable1
3421 3421 Word R/W
enable pressure span compensation of
comp1
Service.Measurement.Compensation.PfactE-
nable2
3422 3422 Word R/W
enable pressure span compensation of
comp2
Service.Measurement.Compensation.PfactE-
nable3
3423 3423 Word R/W
enable pressure span compensation of
comp3
Service.Measurement.Compensation.PfactE-
nable4
3424 3424 Word R/W
enable pressure span compensation of
comp4
Service.Measurement.Compensation.PfactE-
nable5
3425 3425 Word
R/W
enable pressure span compensation of
comp5
Service.Measurement.Compensation.Pfact-
SensorAssign1
3426 3426 Word R/W
assign press-sensor of span comp1
(0=Man, 1=DSP_P1, 2=DSP_P2 etc.)
Service.Measurement.Compensation.Pfact-
SensorAssign2
3427 3427 Word R/W
assign press-sensor of span comp2
(0=Man, 1=DSP_P1, 2=DSP_P2 etc.)
Service.Measurement.Compensation.Pfact-
SensorAssign3
3428 3428 Word R/W
assign press-sensor of span comp3
(0=Man, 1=DSP_P1, 2=DSP_P2 etc.)
Service.Measurement.Compensation.Pfact-
SensorAssign4
3429 3429 Word R/W
assign press-sensor of span comp4
(0=Man, 1=DSP_P1, 2=DSP_P2 etc.)
Service.Measurement.Compensation.Pfact-
SensorAssign5
3430 3430 Word R/W
assign press-sensor of span comp5
(0=Man, 1=DSP_P1, 2=DSP_P2 etc.)
Service.Measurement.Compensation.Tfact-
Coeffs1
6441…
6448
9221…
9224
Float R/W
polynom coeffs for temperature factor
of comp1
Service.Measurement.Compensation.Tfact-
Coeffs2
6449…
6456
9225…
9228
Float R/W
polynom coeffs for temperature factor
of comp2
Service.Measurement.Compensation.Tfact-
Coeffs3
6457…
6464
9229…
9232
Float R/W
polynom coeffs for temperature factor
of comp3
Service.Measurement.Compensation.Tfact-
Coeffs4
6465…
6472
9233…
9236
Float R/W
polynom coeffs for temperature factor
of comp4
