Emerson Process Management GmbH & Co. OHG 9-7
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
04/2010
9
Modbus Commands
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Service.Measurement.Compensation.Tfact-
Coeffs5
6473…
6480
9237…
9240
Float R/W
polynom coeffs for temperature factor
of comp5
Service.Measurement.Compensation.Tfact-
ConcCoeffs1
6481…
6488
9241…
9244
Float R/W
polynom coeffs for conc correction of
temp factor comp1
Service.Measurement.Compensation.Tfact-
ConcCoeffs2
6489…
6496
9245…
9248
Float R/W
polynom coeffs for conc correction of
temp factor comp2
Service.Measurement.Compensation.Tfact-
ConcCoeffs3
6497…
6504
9249…
9252
Float R/W
polynom coeffs for conc correction of
temp factor comp3
Service.Measurement.Compensation.Tfact-
ConcCoeffs4
6505…
6512
9253…
9256
Float R/W
polynom coeffs for conc correction of
temp factor comp4
Service.Measurement.Compensation.Tfact-
ConcCoeffs5
6513…
6520
9257…
9260
Float R/W
polynom coeffs for conc correction of
temp factor comp5
Service.Measurement.Compensation.TfactE-
nable1
3411 3411 Word R/W
enable temperature span compensati-
on of comp1
Service.Measurement.Compensation.TfactE-
nable2
3412 3412 Word R/W
enable temperature span compensati-
on of comp2
Service.Measurement.Compensation.TfactE-
nable3
3413 3413 Word R/W
enable temperature span compensati-
on of comp3
Service.Measurement.Compensation.TfactE-
nable4
3414 3414 Word R/W
enable temperature span compensati-
on of comp4
Service.Measurement.Compensation.TfactE-
nable5
3415 3415 Word R/W
enable temperature span compensati-
on of comp5
Service.Measurement.Compensation.Tfact-
SensorAssign1
3416 3416 Word R/W
assign temp-sensor of span comp1
(0=None, 1=DSP_T1, 2=DSP_T2 etc.)
Service.Measurement.Compensation.Tfact-
SensorAssign2
3417 3417 Word R/W
assign temp-sensor of span comp2
(0=None, 1=DSP_T1, 2=DSP_T2 etc.)
Service.Measurement.Compensation.Tfact-
SensorAssign3
3418 3418 Word R/W
assign temp-sensor of span comp3
(0=None, 1=DSP_T1, 2=DSP_T2 etc.)
Service.Measurement.Compensation.Tfact-
SensorAssign4
3419 3419 Word R/W
assign temp-sensor of span comp4
(0=None, 1=DSP_T1, 2=DSP_T2 etc.)
Service.Measurement.Compensation.Tfact-
SensorAssign5
3420 3420 Word R/W
assign temp-sensor of span comp5
(0=None, 1=DSP_T1, 2=DSP_T2 etc.)
Service.Measurement.Compensation.Tfact-
Temperature1
6531…
6532
9266 Float RO
temperature for span compensation of
comp1
Service.Measurement.Compensation.Tfact-
Temperature2
6533…
6534
9267 Float RO
temperature for span compensation of
comp2
Service.Measurement.Compensation.Tfact-
Temperature3
6535…
6536
9268 Float RO
temperature for span compensation of
comp3
Service.Measurement.Compensation.Tfact-
Temperature4
6537…
6538
9269 Float RO
temperature for span compensation of
comp4
Service.Measurement.Compensation.Tfact-
Temperature5
6539…
6540
9270 Float RO
temperature for span compensation of
comp5
Service.Measurement.Compensation.Toff-
Coeffs1
6401…
6408
9201…
9204
Float R/W
polynom coeffs for temperature offset
of comp1
Service.Measurement.Compensation.Toff-
Coeffs2
6409…
6416
9205…
9208
Float R/W
polynom coeffs for temperature offset
of comp2
