19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
Precautions
The input circuit of the CPU module has restrictions for maximum frequency
If input response time is set, maximum frequency is affected by the setting value.
Under ordinary circumstances, the internal clock counts at 1 MHz (fixed) during operation.
Matched output performance
If output is to Y0 to Y17 using high-speed comparison instructions (DHSCS, DHSCR, DHSZ instruction), high-speed
comparison table, or multiple point output high-speed comparison table, time from pulse inputcomparison of count value
(match)output to Y is 5 s + input response time.
If output is to Y20 or subsequent, time from pulse input to output is affected by communication and user interrupt.
Count range
-2147483648 to +2147483647. These are signed 32-bit ring counters.
Ring length setting is however in the range of 0 to 2147483647.
FX5U-32M, FX5UC-32M FX5U-64M, FX5U-80M Maximum frequency
X0 to X5 X0 to X7 200 KHz
X6 to X17 X10 to X17 10 KHz
