19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
119
19
Assignment for high-speed counters
Input assignment for high-speed counters
Assignment for input devices of high-speed counters is set by parameters.
Assignment is determined according to functions set for each channels by parameter.
When using internal clock, assignment is same as 1-phase, 1-count (S/W) and phase A is not used.
Input assignment of high-speed counters is as follows.
A: A phase input
B: Phase B input (direction switch input is however employed in the case of 1-phase 1-count [H/W])
P: External preset input
E: External enable input
CH High-speed counter
type
X0 X1 X2 X3 X4 X5 X6 X7 X10 X11 X12 X13 X14 X15 X16 X17
CH1 1-phase 1-count (S/W) A P E
1-phase 1-count (H/W) A B P E
1-phase 2-count A B P E
2-phase 2-count A B P E
CH2 1-phase 1-count (S/W) A P E
1-phase 1-count (H/W) A B P E
1-phase 2-count A B P E
2-phase 2-count A B P E
CH3 1-phase 1-count (S/W) A PE
1-phase 1-count (H/W) A B P E
1-phase 2-count A B P E
2-phase 2-count A B P E
CH4 1-phase 1-count (S/W) A PE
1-phase 1-count (H/W) A B P E
1-phase 2-count A B P E
2-phase 2-count A B P E
CH5 1-phase 1-count (S/W) A P E
1-phase 1-count (H/W) ABPE
1-phase 2-count ABPE
2-phase 2-count ABPE
CH6 1-phase 1-count (S/W) A P E
1-phase 1-count (H/W) ABPE
1-phase 2-count ABPE
2-phase 2-count ABPE
CH7 1-phase 1-count (S/W) A P E
1-phase 1-count (H/W) ABPE
1-phase 2-count ABPE
2-phase 2-count ABPE
CH8 1-phase 1-count (S/W) A P E
1-phase 1-count (H/W) AB
1-phase 2-count AB
2-phase 2-count AB
CH1
to
CH8
Internal clock Not used
