APPENDIX
Appendix 3 Error Code
285
A
3663H Axis 3 error stop
(immediately
stop)
• When pulses were being output or
positioning was rising, the PLC stopped
the pulse output immediately by the
pulse stop command or detection of the
all outputs disable flag.
• Eliminate the error that has caused the stop
and restart the positioning.
Error location
information
and system
configuration
information
At END
instruction
execution, at
instruction
execution
3664H Axis 4 error stop
(immediately
stop)
• When pulses were being output or
positioning was rising, the PLC stopped
the pulse output immediately by the
pulse stop command or detection of the
all outputs disable flag.
• Eliminate the error that has caused the stop
and restart the positioning.
Error location
information
and system
configuration
information
At END
instruction
execution, at
instruction
execution
3671H Axis 1 positioning
table operand
error
• The value of an operand in the table is
abnormal. (Other than the positioning
address and command speed)
• Set the correct value to the table. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3672H Axis 2 positioning
table operand
error
• The value of an operand in the table is
abnormal. (Other than the positioning
address and command speed)
• Set the correct value to the table. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3673H Axis 3 positioning
table operand
error
• The value of an operand in the table is
abnormal. (Other than the positioning
address and command speed)
• Set the correct value to the table. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3674H Axis 4 positioning
table operand
error
• The value of an operand in the table is
abnormal. (Other than the positioning
address and command speed)
• Set the correct value to the table. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3681H Axis 1 positioning
table shift error
(table
specification)
• Tables which cannot be used together
were specified for continuous operation.
• The counterpart axis for the interpolation
operation table was specified.
• Observe the restrictions on table operation. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3682H Axis 2 positioning
table shift error
(t
able
specification)
• Tables which cannot be used together
were specified for continuous operation.
• The counterpart axis for the interpolation
operation table was specified.
• Observe the restrictions on table operation. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3683H Axis 3 positioning
table shift error
(table
specification)
• Tables which cannot be used together
were specified for continuous operation.
• The counterpart axis for the interpolation
operation table was specified.
• Observe the restrictions on table operation. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3684H Axis 4 positioning
table shift error
(table
specification)
• Tables which cannot be used together
were specified for continuous operation.
• The counterpart axis for the interpolation
operation table was specified.
• Observe the restrictions on table operation. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3691H Axis 1 positioning
table shift error
(table shift)
• Table shift cannot be completed in time
because one or more tables shifted per
10 ms.
• Set the interval of table shifts to 10 ms or
greater.
Error location
information
and system
configuration
information
At interrupt
occurrence
3692H Axis 2 positioning
table shift error
(table shift)
• Table shift cannot be completed in time
because one or more tables shifted per
10 ms.
• Set the interval of table shifts to 10 ms or
greater.
Error location
information
and system
configuration
information
At interrupt
occurrence
3693H Axis 3 positioning
table shift error
(table shift)
• Table shift cannot be completed in time
because one or more tables shifted per
10 ms.
• Set the interval of table shifts to 10 ms or
greater.
Error location
information
and system
configuration
information
At interrupt
occurrence
Error
code
Error name Error details and cause Action Detailed
information
Diagnostic
timing
