12 DEVICE/LABEL MEMORY AREA SETTING
12.2 The Setting Range of the Capacity of Each Area
93
12
12.2 The Setting Range of the Capacity of Each Area
The setting range of the capacity of each area on the device/label memory is as follows.
Restriction of a label/latch label area capacity
When device area setting using by label/latch label is standard area
Label Area Capacity + Latch Label Area Capacity + Device (standard) Area Capacity 48 K Word (1 K word unit)
When device area setting using by label/latch label is high speed area
Label Area Capacity + Latch Label Area Capacity + Device (high speed) Area Capacity 12 K Word (1 K word unit)
When FB is used
In using FB, it consumes the margin area for a label addition in addition to the label defined for FB.
The following capacities are consumed per FB instance.
Label area: 48 words
Latch area: 16 words
Item Setting range of capacity of each area
Device (high speed) Area Capacity 0 to 12 K words
Device (standard) Area Capacity 0 to 48 K words
Label Area Capacity 0 to 48 K words
Latch Label Area Capacity 0 to 48 K words
