19 BUILT-IN I/O FUNCTION
19.5 FX3-Compatible Pulse Catch Function
19.5 FX3-Compatible Pulse Catch Function
This section explains the FX3-compatible pulse catch function.
Outline of FX3-compatible pulse catch function
An FX3-compatible pulse catch function is mounted on the CPU module,
When the input signal X0 to X7 turns OFFON, a special relay (SM8170 to SM8177) is immediately set to ON by interrupt
processing. Use of these special relays in a normal sequence program enables pulse signals that are incompletely sampled in
regular input processing to be caught.
To use the FX3-compatible pulse catch function, pulse catch setting and the input response time must be set with parameters.
Functions equivalent to the MELSEC Q/L series pulse catch function are also mounted. For details of functions, refer to
Page 184 Pulse Catch Function.
The pulse catch function and FX3-compatible pulse catch function can be used simultaneously.
Specifications of FX3-compatible pulse catch function
This specifications of the FX3-compatible pulse catch function are explained below.
Performance specifications
FX3-compatible pulse catches can be used on inputs X0 to X7.
Input response time
Input response times are shown below.
Assignment of input numbers and special relays
The assignments of input numbers and special relays are explained below.
FX5U-32M, FX5UC-32M FX5U-64M, FX5U-80M Input response time
X0 to X5 X0 to X7 5 s
X6 to X7 100 s
Input number Corresponding special relay
X0 SM8170
X1 SM8171
X2 SM8172
X3 SM8173
X4 SM8174
X5 SM8175
X6 SM8176
X7 SM8177
