APPENDIX
Appendix 2 Special Register List
SD4504 High-speed counter minimum value [Low-order] (CH1) This register stores the high-speed counter minimum value
(CH1).
R/W
SD4505 High-speed counter minimum value [High-order] (CH1)
SD4506 High-speed counter pulse density [Low-order] (CH1) This register stores the high-speed counter pulse density (CH1). R/W
SD4507 High-speed counter pulse density [High-order] (CH1)
SD4508 High-speed counter rotation speed [Low-order] (CH1) This register stores the high-speed counter rotation speed (CH1). R/W
SD4509 High-speed counter rotation speed [High-order] (CH1)
SD4510 High-speed counter preset control switch (CH1) This register stores the high-speed counter preset control switch
(CH1).
R/W
SD4512 High-speed counter preset value [Low-order] (CH1) This register stores the high-speed counter preset value (CH1). R/W
SD4513 High-speed counter preset value [High-order] (CH1)
SD4514 High-speed counter ring length [Low-order] (CH1) This register stores the high-speed counter ring length (CH1). R/W
SD4515 High-speed counter ring length [High-order] (CH1)
SD4516 High-speed counter measurement-unit time [Low-order]
(CH1)
This register stores the high-speed counter measurement-unit
time (CH1).
R/W
SD4517 High-speed counter measurement-unit time [High-order]
(CH1)
SD4518 High-speed counter number of pulses per rotation [Low-
order] (CH1)
This register stores the high-speed counter number of pulses per
rotation (CH1).
R/W
SD4519 High-speed counter number of pulses per rotation [High-
order] (CH1)
SD4530 High-speed counter current value [Low-order] (CH2) This register stores the high-speed counter current value (CH2). R/W
SD4531 High-speed counter current value [High-order] (CH2)
SD4532 High-speed counter maximum value [Low-order] (CH2) This register stores the high-speed counter maximum value
(CH2).
R/W
SD4533 High-speed counter maximum value [High-order] (CH2)
SD4534 High-speed counter minimum value [Low-order] (CH2) This register stores the high-speed counter minimum value
(CH2).
R/W
SD4535 High-speed counter minimum value [High-order] (CH2)
SD4536 High-speed counter pulse density [Low-order] (CH2) This register stores the high-speed counter pulse density (CH2). R/W
SD4537 High-speed counter pulse density [High-order] (CH2)
SD4538 High-speed counter rotation speed [Low-order] (CH2) This register stores the high-speed counter rotation speed (CH2). R/W
SD4539 High-speed counter rotation speed [High-order] (CH2)
SD4540 High-speed counter preset control switch (CH2) This register stores the high-speed counter preset control switch
(CH2).
R/W
SD4542 High-speed counter preset value [Low-order] (CH2) This register stores the high-speed counter preset value (CH2). R/W
SD4543 High-speed counter preset value [High-order] (CH2)
SD4544 High-speed counter ring length [Low-order] (CH2) This register stores the high-speed counter ring length (CH2). R/W
SD4545 High-speed counter ring length [High-order] (CH2)
SD4546 High-speed counter measurement-unit time [Low-order]
(CH2)
This register stores the high-speed counter measurement-unit
time (CH2).
R/W
SD4547 High-speed counter measurement-unit time [High-order]
(CH2)
SD4548 High-speed counter number of pulses per rotation [Low-
order] (CH2)
This register stores the high-speed counter number of pulses per
rotation (CH2).
R/W
SD4549 High-speed counter number of pulses per rotation [High-
order] (CH2)
SD4560 High-speed counter current value [Low-order] (CH3) This register stores the high-speed counter current value (CH3). R/W
SD4561 High-speed counter current value [High-order] (CH3)
SD4562 High-speed counter maximum value [Low-order] (CH3) This register stores the high-speed counter maximum value
(CH3).
R/W
SD4563 High-speed counter maximum value [High-order] (CH3)
SD4564 High-speed counter minimum value [Low-order] (CH3) This register stores the high-speed counter minimum value
(CH3).
R/W
SD4565 High-speed counter minimum value [High-order] (CH3)
SD4566 High-speed counter pulse density [Low-order] (CH3) This register stores the high-speed counter pulse density (CH3). R/W
SD4567 High-speed counter pulse density [High-order] (CH3)
SD4568 High-speed counter rotation speed [Low-order] (CH3) This register stores the high-speed counter rotation speed (CH3). R/W
SD4569 High-speed counter rotation speed [High-order] (CH3)
SD4570 High-speed counter preset control switch (CH3) This register stores the high-speed counter preset control switch
(CH3).
R/W
No. Name Description R/W
