APPENDIX
Appendix 2 Special Register List
263
A
Built-in Ethernet
The special registers for built-in Ethernet are shown below.
R: Read only, R/W: Read/Write
SD9061 Code of communication error at master station This register stores the code of communication error at master
station.
R
SD9062 Code of communication error at slave station No.1 This register stores the code of communication error at slave
station No.1.
R
SD9063 Code of communication error at slave station No.2 This register stores the code of communication error at slave
station No.2.
R
SD9064 Code of communication error at slave station No.3 This register stores the code of communication error at slave
station No.3.
R
SD9065 Code of communication error at slave station No.4 This register stores the code of communication error at slave
station No.4.
R
SD9066 Code of communication error at slave station No.5 This register stores the code of communication error at slave
station No.5.
R
SD9067 Code of communication error at slave station No.6 This register stores the code of communication error at slave
station No.6.
R
SD9068 Code of communication error at slave station No.7 This register stores the code of communication error at slave
station No.7.
R
SD9080 Station number setting This register stores the station number setting. R/W
SD9081 Total slave station number setting This register stores the total slave station number setting. R/W
SD9082 Refresh range setting This register stores the refresh range setting. R
SD9083 Retry count setting This register stores the retry count setting. R
SD9084 Communication time-out setting This register stores the communication time-out setting. R
No. Name Description R/W
SD10050 Local node IP address [Low-order] This register stores the local node IP address. R
SD10051 Local node IP address [High-order]
SD10060 Subnet mask [Low-order] This register stores the subnet mask. R
SD10061 Subnet mask [High-order]
SD10064 Default gateway IP address [Low-order] This register stores the default gateway IP address. R
SD10065 Default gateway IP address [High-order]
SD10074 Local node MAC address This register stores the local node MAC address (5 and 6 bytes). R
SD10075 Local node MAC address This register stores the local node MAC address (3 and 4 bytes). R
SD10076 Local node MAC address This register stores the local node MAC address (1 and 2 bytes). R
SD10082 Communication speed setting This register stores the communication speed setting. R
SD10084 MELSOFT connection TCP port No. This register stores the MELSOFT connection TCP port No. R
SD10086 MELSOFT direct connection port No. This register stores the MELSOFT direct connection port No. R
SD10130 Connection No.1 latest error code This register stores the connection No.1 latest error code. R
SD10131 Connection No.2 latest error code This register stores the connection No.2 latest error code. R
SD10132 Connection No.3 latest error code This register stores the connection No.3 latest error code. R
SD10133 Connection No.4 latest error code This register stores the connection No.4 latest error code. R
SD10134 Connection No.5 latest error code This register stores the connection No.5 latest error code. R
SD10135 Connection No.6 latest error code This register stores the connection No.6 latest error code. R
SD10136 Connection No.7 latest error code This register stores the connection No.7 latest error code. R
SD10137 Connection No.8 latest error code This register stores the connection No.8 latest error code. R
SD10270 Remote password lock status connection No. 1 to 8 b0: Connection No.1
b1: Connection No.2
b2: Connection No.3
b3: Connection No.4
b4: Connection No.5
b5: Connection No.6
b6: Connection No.7
b7: Connection No.8
0: Unlock status/remote password setting none
1: Lock status
R
No. Name Description R/W
