APPENDIX
Appendix 3 Error Code
3514H Operation error • The auto tuning result in the step
response method is abnormal.
• The deviation at start of auto tuning is
150 or less.
• The deviation at end of auto tuning is 1/3
or more of the deviation at start of auto
tuning.
• Check the measured value and target value,
and then execute auto tuning again.
Error location
information
At instruction
execution
3515H Operation error • The operation direction estimated from
the measured value at the start of auto
tuning in the step response method was
different from the actual operation
direction of the output during auto tuning.
• Correct the relationship among the target
value, output value for auto tuning, and the
measured value, and then execute auto
tuning again.
Error location
information
At instruction
execution
3516H Operation error • Because the set value fluctuated during
auto tuning in the step response method,
auto tuning was not executed correctly.
• Set the sampling time to a value larger than
the output change cycle, or set a larger value
for the input filter constant. After changing
the setting, execute auto tuning again.
Error location
information
At instruction
execution
3517H Operation error • The output set value upper limit for auto
tuning is lower than the lower limit.
• Verify that the target setting contents are
correct.
Error location
information
At instruction
execution
3518H Operation error • A value outside the allowable range was
set to the PV threshold for auto tuning.
• Verify that the target setting contents are
correct.
Error location
information
At instruction
execution
3519H Operation error • Operation is not performed normally
because devices occupied by the PID
instruction were overwritten.
• Ensure that devices occupied by PID
instruction are not overwritten in the
program.
Error location
information
At instruction
execution
351AH Operation error • The auto tuning time is longer than
necessary.
• Increase the difference (ULV - LLV) between
the upper limit and lower limit of the output
value for auto tuning, set a smaller value to
the input filter constant (α), or set a smaller
value to the PV threshold (SHPV) for auto
tuning, and then check the result for
improvement.
Error location
information
At instruction
execution
350BH Operation error • The variation of the measured value is
too small compared with the output
value.
• Multiply the measured value (PV) by "10" so
that the variation of the measured value will
increase during auto tuning. The operation is
continued with KP = 32767.
Error location
information
At instruction
execution
350CH Operation error • The auto tuning time is longer than
necessary.
• Increase the difference (ULV - LLV) between
the upper limit and lower limit of the output
value for auto tuning, set a smaller value to
the input filter constant (α), or set a smaller
value to the PV threshold (SHPV) for auto
tuning, and then check the result for
improvement. The operation is continued
with KP = 32767.
Error location
information
A
t instruction
execution
350DH Operation error • The auto tuning time is longer than
necessary.
• Increase the difference (ULV - LLV) between
the upper limit and lower limit of the output
value for auto tuning, set a smaller value to
the input filter constant (α), or set a smaller
value to the PV threshold (SHPV) for auto
tuning, and then check the result for
improvement. The operation is continued
with KP = 32767.
Error location
information
At instruction
execution
3580H Operation error • An instruction that cannot be used in an
interrupt routine program is used.
• Modify the program so that no instruction
whose use is disabled by the interrupt
routine program is used.
Error location
information
At instruction
execution
3581H Operation error • Modules subsequent to the bus
conversion module are using an operand
that cannot be used.
• Modify the program so that no operand
whose use is disabled for modules
subsequent to the bus conversion module is
used.
Error location
information
At instruction
execution
3582H Operation error • An instruction that cannot be used in an
interrupt routine program is used.
• Modify the program so that no instruction
whose use is disabled by the interrupt
routine program is used.
Error location
information
At instruction
execution
3600H Operation error • The channel specified by instructions
using communication functions or built-in
I/O does not have the appropriate
parameter.
• Verify that the parameter setting of the
channel specified by instructions using
communication functions or built-in I/O is
correct.
Error location
information
At instruction
execution
Error
code
Error name Error details and cause Action Detailed
information
Diagnostic
timing
