19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
Parameters are enabled when the CPU module is powered ON or after a reset. In addition, operations
different from the parameter settings are possible by transferring values to special relays and special registers
while changing these values in the program.
For details concerning special relays and specials registers for high-speed counters, refer to Page 137
Special relay list, Page 148 Special registers list.
Rotational speed measurement mode start/stop
The rotational speed measurement mode cannot measure by setting the parameter alone.
The HIOEN instruction is required to start/stop measurement.
For the HIOEN instruction, refer to MELSEC iQ-F FX5 Programming Manual (Instructions, Standard Functions/Function
Blocks).
Rotational speed
Rotational speed is stored in the special register for each channel.
For details concerning specials registers for high-speed counters, refer to Page 148 Special registers list.
Preset Input Enable/
Disable
Not available for high-speed counters (rotational speed
measurement mode).
Input Logic
Preset Value
Input Comparison Enable/
Disable
Control Switch
Enable Input Enable/
Disable
Set whether to "enable" or "disable" the enable input. • Disable
• Enable
Input Logic Set the enable input logic value. • Positive Logic
• Negative Logic
Ring Length Enable/
Disable
Not available for high-speed counters (rotational speed
measurement mode).
Ring Length
Measurement Unit Time Set measurement unit time. (Unit: ms) 1 to 2147483647
Pulses No. of per Rotation Set the No. of pulses per rotation. (Unit: ms) 1 to 2147483647
Item Description Setting range Default
