Appendix 2 Special Register List
261
A
SD8573 Receive sum (received data) (ch2) This register stores the receive sum (received data) (ch2). R
SD8574 Receive sum (received result) (ch2) This register stores the receive sum (received result) (ch2). R
SD8575 Send sum (ch2) This register stores the send sum (ch2). R
SD8580 Remaining points of send data (ch3) This register stores the remaining points of send data (ch3). R
SD8581 Receive data points monitor (ch3) This register stores the receive data points monitor (ch3). R
SD8583 Receive sum (received data) (ch3) This register stores the receive sum (received data) (ch3). R
SD8584 Receive sum (received result) (ch3) This register stores the receive sum (received result) (ch3). R
SD8585 Send sum (ch3) This register stores the send sum (ch3). R
SD8590 Remaining points of send data (ch4) This register stores the remaining points of send data (ch4). R
SD8591 Receive data points monitor (ch4) This register stores the receive data points monitor (ch4). R
SD8593 Receive sum (received data) (ch4) This register stores the receive sum (received data) (ch4). R
SD8594 Receive sum (received result) (ch4) This register stores the receive sum (received result) (ch4). R
SD8595 Send sum (ch4) This register stores the send sum (ch4). R
SD8621 Timeout time (ch1) This register stores the timeout time (ch1). R
SD8622 8-bit processing mode (ch1) This register stores the 8-bit processing mode (ch1). R
SD8623 Header 1 and 2 (ch1) This register stores the header 1 and 2 (ch1). R
SD8624 Header 3 and 4 (ch1) This register stores the header 3 and 4 (ch1). R
SD8625 Terminator 1 and 2 (ch1) This register stores the terminator 1 and 2 (ch1). R
SD8626 Terminator 3 and 4 (ch1) This register stores the terminator 3 and 4 (ch1). R
SD8631 Timeout time (ch2) This register stores the timeout time (ch2). R
SD8632 8-bit processing mode (ch2) This register stores the 8-bit processing mode (ch2). R
SD8633 Header 1 and 2 (ch2) This register stores the header 1 and 2 (ch2). R
SD8634 Header 3 and 4 (ch2) This register stores the header 3 and 4 (ch2). R
SD8635 Terminator 1 and 2 (ch2) This register stores the terminator 1 and 2 (ch2). R
SD8636 Terminator 3 and 4 (ch2) This register stores the terminator 3 and 4 (ch2). R
SD8641 Timeout time (ch3) This register stores the timeout time (ch3). R
SD8642 8-bit processing mode (ch3) This register stores the 8-bit processing mode (ch3). R
SD8643 Header 1 and 2 (ch3) This register stores the header 1 and 2 (ch3). R
SD8644 Header 3 and 4 (ch3) This register stores the header 3 and 4 (ch3). R
SD8645 Terminator 1 and 2 (ch3) This register stores the terminator 1 and 2 (ch3). R
SD8646 Terminator 3 and 4 (ch3) This register stores the terminator 3 and 4 (ch3). R
SD8651 Timeout time (ch4) This register stores the timeout time (ch4). R
SD8652 8-bit processing mode (ch4) This register stores the 8-bit processing mode (ch4). R
SD8653 Header 1 and 2 (ch4) This register stores the header 1 and 2 (ch4). R
SD8654 Header 3 and 4 (ch4) This register stores the header 3 and 4 (ch4). R
SD8655 Terminator 1 and 2 (ch4) This register stores the terminator 1 and 2 (ch4). R
SD8656 Terminator 3 and 4 (ch4) This register stores the terminator 3 and 4 (ch4). R
SD8740 Station number setting (ch1) This register stores the station number setting (ch1). R/W
SD8741 Message frame and form (ch1) This register stores the message frame and form (ch1). R
SD8742 Timeout time (ch1) This register stores the timeout time (ch1). R
SD8750 Station number setting (ch2) This register stores the station number setting (ch2). R/W
SD8751 Message frame and form (ch2) This register stores the message frame and form (ch2). R
SD8752 Timeout time (ch2) This register stores the timeout time (ch2). R
SD8760 Station number setting (ch3) This register stores the station number setting (ch3). R/W
SD8761 Message frame and form (ch3) This register stores the message frame and form (ch3). R
SD8762 Timeout time (ch3) This register stores the timeout time (ch3). R
SD8770 Station number setting (ch4) This register stores the station number setting (ch4). R/W
SD8771 Message frame and form (ch4) This register stores the message frame and form (ch4). R
SD8772 Timeout time (ch4) This register stores the timeout time (ch4). R
SD8800 Current retry value (ch1) This register stores the current retry value (ch1). R
SD8810 Current retry value (ch2) This register stores the current retry value (ch2). R
SD8820 Current retry value (ch3) This register stores the current retry value (ch3). R
SD8830 Current retry value (ch4) This register stores the current retry value (ch4). R
No. Name Description R/W
