APPENDIX
Appendix 2 Special Register List
SD10878 Connection No.7 protocol execution count Stores the number of protocol executions in connection No.7.
0: Protocol not executed
1 to 65535: Number of executions
R
SD10879 Connection No.7 protocol cancellation specification Cancels the protocol executed in connection No.7.
0: No cancellation instruction
1: Cancellation request (set by user)
2: Cancellation completed (set by system)
R/W
SD10880 Connection No.8 protocol execution status Stores the status of the protocol being executed at connection
No.8.
0: Unexecuted
1: Waiting for transmission
2: Sending
3: Waiting for data reception
4: Receiving
5: Execution completed
R
SD10882 Connection No.8 received data verification result (receive
packet No.1)
Stores the verification results of receive packet No.1.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10883 Connection No.8 received data verification result (receive
packet No.2)
Stores the verification results of receive packet No.2.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10884 Connection No.8 received data verification result (receive
packet No.3)
Stores the verification results of receive packet No.3.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10885 Connection No.8 received data verification result (receive
packet No.4)
Stores the verification results of receive packet No.4.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10886 Connection No.8 received data verification result (receive
packet No.5)
Stores the verification results of receive packet No.5.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10887 Connection No.8 received data verification result (receive
packet No.6)
Stores the verification results of receive packet No.6.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10888 Connection No.8 received data verification result (receive
packet No.7)
Stores the verification results of receive packet No.7.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10889 Connection No.8 received data verification result (receive
packet No.8)
Stores the verification results of receive packet No.8.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10890 Connection No.8 received data verification result (receive
packet No.9)
Stores the verification results of receive packet No.9.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10891 Connection No.8 received data verification result (receive
packet No.10)
Stores the verification results of receive packet No.10.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10892 Connection No.8 received data verification result (receive
packet No.11)
Stores the verification results of receive packet No.11.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10893 Connection No.8 received data verification result (receive
packet No.12)
Stores the verification results of receive packet No.12.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10894 Connection No.8 received data verification result (receive
packet No.13)
Stores the verification results of receive packet No.13.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10895 Connection No.8 received data verification result (receive
packet No.14)
Stores the verification results of receive packet No.14.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10896 Connection No.8 received data verification result (receive
packet No.15)
Stores the verification results of receive packet No.15.
E
lement No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10897 Connection No.8 received data verification result (receive
packet No.16)
Stores the verification results of receive packet No.16.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
No. Name Description R/W
