152
19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
Special register details
This section describes details about the special registers used with the high-speed counters.
High-speed counter current value
These devices store the current values of the high-speed counters.
■Corresponding devices
The device numbers corresponding to each channel are as follows.
■Description
These devices stores the current values of the high-speed counters.
These are signed 32-bit ring counters. (Upper limit value+1 changes to lower limit value, lower limit value-1 changes to
upper limit value.)
When the ring length is not set, lower limit value: -2147483648, upper limit value: 2147483647.
When the ring length is set, lower limit value: 0, upper limit value: ring length-1.
• To rewrite the current value, use the HCMOV instruction and transfer the desired value. However, this is the
upper limit when set to a value that exceeds the upper limit value, and this is the lower limit value when set
to a value that is less than the lower limit value.
• If the current value falls outside the ring length range when the ring length is set, the upper and lower limit
values of the ring length are ignored and the current value is used.
• The current value is retained even when the power is OFF.
■Update timing
The current value of the high-speed counter is updated in END processing or when the HCMOV instruction is executed.
Further, when the FX3 compatible high-speed counter function is valid, the value is updated also when UDCNTF instruction is
executed.
■Clear timing
The timing when the device is cleared is as follows.
• Cleared by the DHCMOV instruction
• When the RST LC instruction executes ON (only when the FX3 compatible high-speed counter function is valid and the
applicable LC device is used)
• Power ON, reset, RUN→STOP (only when the FX3 compatible high-speed counter function is valid and the applicable LC
device is used)
High-speed counter maximum value
These devices store the maximum values of the high-speed counters.
■Corresponding devices
The device numbers corresponding to each channel are as follows.
■Description
These devices stores the maximum values of the high-speed counters.
• To rewrite the maximum value, only the HCMOV instruction can be used.
• These devices also operate when the FX3 compatible high-speed counter function is valid.
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
SD4501,
SD4500
SD4531,
SD4530
SD4561,
SD4560
SD4591,
SD4590
SD4621,
SD4620
SD4651,
SD4650
SD4681,
SD4680
SD4711,
SD4710
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
SD4503,
SD4502
SD4533,
SD4532
SD4563,
SD4562
SD4593,
SD4592
SD4623,
SD4622
SD4653,
SD4652
SD4683,
SD4682
SD4713,
SD4712
