160
19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
Multi-point output high-speed comparison table comparison number
This device stores the number of the table currently being compared in the multi-point output high-speed comparison tables.
■Corresponding devices
The device number is shared for all channels.
■Description
This device stores the number of the table currently being compared in the multi-point output high-speed comparison tables. If
0, the multi-point output high-speed comparison tables have stopped.
• When rewriting the comparison value or output data for the multi-point output high-speed comparison
tables, the table numbers from the table numbers that follow after the next table number of the table being
compared can be rewritten.
• The table number being compared and the next table number after that can be rewritten, but they will not be
compared.
• These devices also operate when the FX3 compatible high-speed counter function is valid.
■Clear timing
The timing when the device is cleared is as follows.
• Power ON, Reset, STOPRUN
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
SD5000
