Appendix 2 Special Register List
SD10758 Connection No.1 protocol execution count Stores the number of protocol executions in Connection No.1.
0: Protocol not executed
1 to 65535: Number of executions
R
SD10759 Connection No.1 protocol cancellation specification Cancels the protocol executed in connection No.1.
0: No cancellation instruction
1: Cancellation request (set by user)
2: Cancellation completed (set by system)
R/W
SD10760 Connection No.2 protocol execution status Stores the status of the protocol being executed at connection
No.2.
0: Unexecuted
1: Waiting for transmission
2: Sending
3: Waiting for data reception
4: Receiving
5: Execution completed
R
SD10762 Connection No.2 received data verification result (receive
packet No.1)
Stores the verification results of receive packet No.1.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10763 Connection No.2 received data verification result (receive
packet No.2)
Stores the verification results of receive packet No.2.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10764 Connection No.2 received data verification result (receive
packet No.3)
Stores the verification results of receive packet No.3.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10765 Connection No.2 received data verification result (receive
packet No.4)
Stores the verification results of receive packet No.4.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10766 Connection No.2 received data verification result (receive
packet No.5)
Stores the verification results of receive packet No.5.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10767 Connection No.2 received data verification result (receive
packet No.6)
Stores the verification results of receive packet No.6.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10768 Connection No.2 received data verification result (receive
packet No.7)
Stores the verification results of receive packet No.7.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10769 Connection No.2 received data verification result (receive
packet No.8)
Stores the verification results of receive packet No.8.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10770 Connection No.2 received data verification result (receive
packet No.9)
Stores the verification results of receive packet No.9.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10771 Connection No.2 received data verification result (receive
packet No.10)
Stores the verification results of receive packet No.10.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10772 Connection No.2 received data verification result (receive
packet No.11)
Stores the verification results of receive packet No.11.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10773 Connection No.2 received data verification result (receive
packet No.12)
Stores the verification results of receive packet No.12.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10774 Connection No.2 received data verification result (receive
packet No.13)
Stores the verification results of receive packet No.13.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10775 Connection No.2 received data verification result (receive
packet No.14)
Stores the verification results of receive packet No.14.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10776 Connection No.2 received data verification result (receive
packet No.15)
Stores the verification results of receive packet No.15.
E
lement No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10777 Connection No.2 received data verification result (receive
packet No.16)
Stores the verification results of receive packet No.16.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
