150
19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
SD4622 High-speed counter maximum value (CH5) -2147483648 to +2147483647 -2147483648 R/W
SD4623
SD4624 High-speed counter minimum value (CH5) -2147483648 to +2147483647 2147483647 R/W
SD4625
SD4626 High-speed counter pulse density (CH5) 0 to 2147483647 0 R/W
SD4627
SD4628 High-speed counter rotational speed (CH5) 0 to 2147483647 0 R/W
SD4629
SD4630 High-speed counter preset control switch (CH5) 0: Rising edge
1: Falling edge
2: Both edges
3: Constant when ON
Parameter set value R/W
SD4631 Not used
SD4632 High-speed counter preset value (CH5) -2147483648 to +2147483647 Parameter set value R/W
SD4633
SD4634 High-speed counter ring length (CH5) 2 to 2147483647 Parameter set value R/W
SD4635
SD4636 High-speed counter measurement unit time (CH5) 1 to 2147483647 Parameter set value R/W
SD4637
SD4638 High-speed counter number of pulses per rotation (CH5) 1 to 2147483647 Parameter set value R/W
SD4639
SD4640 to SD4649 Not used
SD4650 High-speed counter current value (CH6) -2147483648 to +2147483647 0 R/W
SD4651
SD4652 High-speed counter maximum value (CH6) -2147483648 to +2147483647 -2147483648 R/W
SD4653
SD4654 High-speed counter minimum value (CH6) -2147483648 to +2147483647 2147483647 R/W
SD4655
SD4656 High-speed counter pulse density (CH6) 0 to 2147483647 0 R/W
SD4657
SD4658 High-speed counter rotational speed (CH6) 0 to 2147483647 0 R/W
SD4659
SD4660 High-speed counter preset control switch (CH6) 0: Rising edge
1: Falling edge
2: Both edges
3: Constant when ON
Parameter set value R/W
SD4661 Not used
SD4662 High-speed counter preset value (CH6) -2147483648 to +2147483647 Parameter set value R/W
SD4663
SD4664 High-speed counter ring length (CH6) 2 to 2147483647 Parameter set value R/W
SD4665
SD4666 High-speed counter measurement unit time (CH6) 1 to 2147483647 Parameter set value R/W
SD4667
SD4668 High-speed counter number of pulses per rotation (CH6) 1 to 2147483647 Parameter set value R/W
SD4669
SD4670 to SD4679 Not used
SD4680 High-speed counter current value (CH7) -2147483648 to +2147483647 0 R/W
SD4681
SD4682 High-speed counter maximum value (CH7) -2147483648 to +2147483647 -2147483648 R/W
SD4683
SD4684 High-speed counter minimum value (CH7) -2147483648 to +2147483647 2147483647 R/W
SD4685
SD4686 High-speed counter pulse density (CH7) 0 to 2147483647 0 R/W
SD4687
Special register Function Range Default R/W
