19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
147
19
Update timing
The timing of device update is as follows.
Multi-point output high-speed comparison table completion
This device turns ON when the high-speed counter's multi-point output high-speed comparison tables have finished
comparing all of the set tables.
Corresponding devices
The device number is shared for all channels.
Operation Description
The content of the operation when ON and when OFF is as follows.
These devices also operate when the FX3 compatible high-speed counter function is valid.
Update timing
The timing of device update is as follows.
ON OFF
Match output driven by the HIOEN instruction
ON execution by DHSCS, DHSCR, DHSZ instruction
Match output stopped by the HIOEN instruction and DHSCS, DHSCR,
DHSZ instructions all OFF
Power ON, reset, STOP, PAUSE
SM8034 turned ON
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
SM5001
Operation when ON Operation when OFF
Multi-point output high-speed comparison table completion
The comparison of the final table has finished
Multi-point output high-speed comparison tables not finished
The comparison has not finished up to the final table
ON OFF
When multi-point output high-speed comparison tables have finished
processing the set amount of tables
When OFF by the user
Power ON, reset, STOP, PAUSE
