19 BUILT-IN I/O FUNCTION
19.1 High-speed Counter Function
149
19
SD4548 High-speed counter number of pulses per rotation (CH2) 1 to 2147483647 Parameter set value R/W
SD4549
SD4550 to SD4559 Not used
SD4560 High-speed counter current value (CH3) -2147483648 to +2147483647 0 R/W
SD4561
SD4562 High-speed counter maximum value (CH3) -2147483648 to +2147483647 -2147483648 R/W
SD4563
SD4564 High-speed counter minimum value (CH3) -2147483648 to +2147483647 2147483647 R/W
SD4565
SD4566 High-speed counter pulse density (CH3) 0 to 2147483647 0 R/W
SD4567
SD4568 High-speed counter rotational speed (CH3) 0 to 2147483647 0 R/W
SD4569
SD4570 High-speed counter preset control switch (CH3) 0: Rising edge
1: Falling edge
2: Both edges
3: Constant when ON
Parameter set value R/W
SD4571 Not used
SD4572 High-speed counter preset value (CH3) -2147483648 to +2147483647 Parameter set value R/W
SD4573
SD4574 High-speed counter ring length (CH3) 2 to 2147483647 Parameter set value R/W
SD4575
SD4576 High-speed counter measurement unit time (CH3) 1 to 2147483647 Parameter set value R/W
SD4577
SD4578 High-speed counter number of pulses per rotation (CH3) 1 to 2147483647 Parameter set value R/W
SD4579
SD4580 to SD4589 Not used
SD4590 High-speed counter current value (CH4) -2147483648 to +2147483647 0 R/W
SD4591
SD4592 High-speed counter maximum value (CH4) -2147483648 to +2147483647 -2147483648 R/W
SD4593
SD4594 High-speed counter minimum value (CH4) -2147483648 to +2147483647 2147483647 R/W
SD4595
SD4596 High-speed counter pulse density (CH4) 0 to 2147483647 0 R/W
SD4597
SD4598 High-speed counter rotational speed (CH4) 0 to 2147483647 0 R/W
SD4599
SD4600 High-speed counter preset control switch (CH4) 0: Rising edge
1: Falling edge
2: Both edges
3: Constant when ON
Parameter set value R/W
SD4601 Not used
SD4602 High-speed counter preset value (CH4) -2147483648 to +2147483647 Parameter set value R/W
SD4603
SD4604 High-speed counter ring length (CH4) 2 to 2147483647 Parameter set value R/W
SD4605
SD4606 High-speed counter measurement unit time (CH4) 1 to 2147483647 Parameter set value R/W
SD4607
SD4608 High-speed counter number of pulses per rotation (CH4) 1 to 2147483647 Parameter set value R/W
SD4609
SD4610 to SD4619 Not used
SD4620 High-speed counter current value (CH5) -2147483648 to +2147483647 0 R/W
SD4621
Special register Function Range Default R/W
