APPENDIX
Appendix 3 Error Code
283
A
3611H CH1 pulse width,
period setting
error
• The value of the special register to set
the pulse width and cycle of the PWM
instruction is abnormal.
• Modify the value of the special register and
restart PWM.
Error location
information
and system
configuration
information
At END
instruction
execution
3612H CH2 pulse width,
period setting
error
• The value of the special register to set
the pulse width and cycle of the PWM
instruction is abnormal.
• Modify the value of the special register and
restart PWM.
Error location
information
and system
configuration
information
At END
instruction
execution
3613H CH3 pulse width,
period setting
error
• The value of the special register to set
the pulse width and cycle of the PWM
instruction is abnormal.
• Modify the value of the special register and
restart PWM.
Error location
information
and system
configuration
information
At END
instruction
execution
3614H CH4 pulse width,
period setting
error
• The value of the special register to set
the pulse width and cycle of the PWM
instruction is abnormal.
• Modify the value of the special register and
restart PWM.
Error location
information
and system
configuration
information
At END
instruction
execution
3621H Axis 1 limit
detection error
• Both the forward and reverse limits were
detected at the time of zero return or the
limit of the moving direction was detected
after the near-point dog was detected.
• Recheck the relationship between the near-
point dog and limits.
Error location
information
and system
configuration
information
At END
instruction
execution, at
instruction
execution
3622H Axis 2 limit
detection error
• Both the forward and reverse limits were
detected at the time of zero return or the
limit of the moving direction was detected
after the near-point dog was detected.
• Recheck the relationship between the near-
point dog and limits.
Error location
information
and system
configuration
information
At END
instruction
execution, at
instruction
execution
3623H Axis 3 limit
detection error
• Both the forward and reverse limits were
detected at the time of zero return or the
limit of the moving direction was detected
after the near-point dog was detected.
• Recheck the relationship between the near-
point dog and limits.
Error location
information
and system
configuration
information
At END
instruction
execution, at
instruction
execution
3624H Axis 4 limit
detection error
•
Both the forward and reverse limits were
detected at the time of zero return or the
limit of the moving direction was detected
after the near-point dog was detected.
• Recheck the relationship between the near-
point dog and limits.
Error location
information
and system
configuration
information
At END
instruction
execution, at
instruction
execution
3631H Axis 1 positioning
address error
• The 32-bit range was exceeded when
the unit of the positioning address was
converted.
• The total transfer distance before and
after the interrupt of the DVIT instruction
or 1-speed positioning with interruption
exceeded 7FFFFFFFH.
• Pulses of 7FFFFFFFH or greater are
needed to specify an absolute address.
• Start the positioning within specifications. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3632H Axis 2 positioning
address error
• The 32-bit range was exceeded when
the unit of the positioning address was
converted.
• The total transfer distance before and
after the interrupt of the DVIT instruction
or 1-speed positioning with interruption
exceeded 7FFFFFFFH.
• Pulses of 7FFFFFFFH or greater are
needed to specify an absolute address.
• Start the positioning within specifications. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
3633H Axis 3 positioning
address error
• The 32-bit range was exceeded when
the unit of the positioning address was
converted.
• The total transfer distance before and
after the interrupt of the DVIT instruction
or 1-speed positioning with interruption
exceeded 7FFFFFFFH.
• Pulses of 7FFFFFFFH or greater are
needed to specify an absolute address.
• Start the positioning within specifications. Error location
information
and system
configuration
information
At END
instruction
execution, at
interrupt
occurrence
Error
code
Error name Error details and cause Action Detailed
information
Diagnostic
timing
