APPENDIX
Appendix 2 Special Register List
251
A
SD4714 High-speed counter minimum value [Low-order] (CH8) This register stores the high-speed counter minimum value
(CH8).
R/W
SD4715 High-speed counter minimum value [High-order] (CH8)
SD4716 High-speed counter pulse density [Low-order] (CH8) This register stores the high-speed counter pulse density (CH8). R/W
SD4717 High-speed counter pulse density [High-order] (CH8)
SD4718 High-speed counter rotation speed [Low-order] (CH8) This register stores the high-speed counter rotation speed (CH8). R/W
SD4719 High-speed counter rotation speed [High-order] (CH8)
SD4720 High-speed counter preset control switch (CH8) This register stores the high-speed counter preset control switch
(CH8).
R/W
SD4722 High-speed counter preset value [Low-order] (CH8) This register stores the high-speed counter preset value (CH8). R/W
SD4723 High-speed counter preset value [High-order] (CH8)
SD4724 High-speed counter ring length [Low-order] (CH8) This register stores the high-speed counter ring length (CH8). R/W
SD4725 High-speed counter ring length [High-order] (CH8)
SD4726 High-speed counter measurement-unit time [Low-order]
(CH8)
This register stores the high-speed counter measurement-unit
time (CH8).
R/W
SD4727 High-speed counter measurement-unit time [High-order]
(CH8)
SD4728 High-speed counter number of pulses per rotation [Low-
order] (CH8)
This register stores the high-speed counter number of pulses per
rotation (CH8).
R/W
SD4729 High-speed counter number of pulses per rotation [High-
order] (CH8)
SD4982 High-speed comparison table (high-speed compare
instruction) error code
This register stores the high-speed comparison table (high-speed
compare instruction) error code.
R/W
SD5000 Multi-point output high-speed comparison table
comparison number
This register stores the multi-point output high-speed comparison
table comparison number.
R
SD5020 Pulse width measurement rising ring counter value [Low-
order] (CH1)
This register stores the pulse width measurement rising ring
counter value (CH1).
R/W
SD5021 Pulse width measurement rising ring counter value [High-
order] (CH1)
SD5022 Pulse width measurement falling ring counter value [Low-
order] (CH1)
This register stores the pulse width measurement falling ring
counter value (CH1).
R/W
SD5023 Pulse width measurement falling ring counter value [High-
order] (CH1)
SD5024 Pulse width measurement latest value [Low-order] (CH1) This register stores the pulse width measurement latest value
(CH1).
R/W
SD5025 Pulse width measurement latest value [High-order] (CH1)
SD5026 Pulse width measurement maximum value [Low-order]
(CH1)
This register stores the pulse width measurement maximum
value (CH1).
R/W
SD5027 Pulse width measurement maximum value [High-order]
(CH1)
SD5028 Pulse width measurement minimum value [Low-order]
(CH1)
This register stores the pulse width measurement minimum value
(CH1).
R/W
SD5029 Pulse width measurement minimum value [High-order]
(CH1)
SD5030 Pulse width measurement cycle latest value [Low-order]
(CH1)
This register stores the pulse width measurement cycle latest
value (CH1).
R/W
SD5031 Pulse width measurement cycle latest value [High-order]
(CH1)
SD5032 Pulse width measurement cycle maximum value [Low-
order] (CH1)
This register stores the pulse width measurement cycle maximum
value (CH1).
R/W
SD5033 Pulse width measurement cycle maximum value [High-
order] (CH1)
SD5034 Pulse width measurement cycle minimum value [Low-
order] (CH1)
This register stores the pulse width measurement cycle minimum
value (CH1).
R/W
SD5035 Pulse width measurement cycle minimum value [High-
order] (CH1)
SD5040 Pulse width measurement rising ring counter value [Low-
order] (CH2)
This register stores the pulse width measurement rising ring
counter value (CH2).
R/W
SD5041 Pulse width measurement rising ring counter value [High-
order] (CH2)
No. Name Description R/W
