APPENDIX
Appendix 1 Special Relay List
227
A
SM4521 High-speed counter pulse density/Rotation speed
measurement (CH6)
OFF: Stopped
ON: Measurement
R
SM4522 High-speed counter pulse density/Rotation speed
measurement (CH7)
OFF: Stopped
ON: Measurement
R
SM4523 High-speed counter pulse density/Rotation speed
measurement (CH8)
OFF: Stopped
ON: Measurement
R
SM4532 High-speed counter overflow (CH1) OFF: No error
ON: Overflow
R/W
SM4533 High-speed counter overflow (CH2) OFF: No error
ON: Overflow
R/W
SM4534 High-speed counter overflow (CH3) OFF: No error
ON: Overflow
R/W
SM4535 High-speed counter overflow (CH4) OFF: No error
ON: Overflow
R/W
SM4536 High-speed counter overflow (CH5) OFF: No error
ON: Overflow
R/W
SM4537 High-speed counter overflow (CH6) OFF: No error
ON: Overflow
R/W
SM4538 High-speed counter overflow (CH7) OFF: No error
ON: Overflow
R/W
SM4539 High-speed counter overflow (CH8) OFF: No error
ON: Overflow
R/W
SM4548 High-speed counter underflow (CH1) OFF: No error
ON: Underflow
R/W
SM4549 High-speed counter underflow (CH2) OFF: No error
ON: Underflow
R/W
SM4550 High-speed counter underflow (CH3) OFF: No error
ON: Underflow
R/W
SM4551 High-speed counter underflow (CH4) OFF: No error
ON: Underflow
R/W
SM4552 High-speed counter underflow (CH5) OFF: No error
ON: Underflow
R/W
SM4553 High-speed counter underflow (CH6) OFF: No error
ON: Underflow
R/W
SM4554 High-speed counter underflow (CH7) OFF: No error
ON: Underflow
R/W
SM4555 High-speed counter underflow (CH8) OFF: No error
ON: Underflow
R/W
SM4564 High-speed counter count direction monitor (CH1) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4565 High-speed counter count direction monitor (CH2) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4566 High-speed counter count direction monitor (CH3) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4567 High-speed counter count direction monitor (CH4) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4568 High-speed counter count direction monitor (CH5) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4569 High-speed counter count direction monitor (CH6) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4570 High-speed counter count direction monitor (CH7) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4571 High-speed counter count direction monitor (CH8) (1-
phase 2-input, 2-phase 2-input)
OFF: Up-counting
ON: Down-counting
R
SM4
580 High-speed counter count switching (CH1) (1-phase 1-
input S/W)
OFF: Up-counting
ON: Down-counting
R/W
SM4581 High-speed counter count switching (CH2) (1-phase 1-
input S/W)
OFF: Up-counting
ON: Down-counting
R/W
SM4582 High-speed counter count switching (CH3) (1-phase 1-
input S/W)
OFF: Up-counting
ON: Down-counting
R/W
