APPENDIX
Appendix 2 Special Register List
SD10271 Remote password lock status system port b2: MELSOFT application communication port (TCP)
b3: MELSOFT direct connection
0: Unlock status/remote password setting none
1: Lock status
R
SD10320 Connection 1 continuous unlock failure number of times This register stores the connection 1 continuous unlock failure
number of times.
R
SD10321 Connection 2 continuous unlock failure number of times This register stores the connection 2 continuous unlock failure
number of times.
R
SD10322 Connection 3 continuous unlock failure number of times This register stores the connection 3 continuous unlock failure
number of times.
R
SD10323 Connection 4 continuous unlock failure number of times This register stores the connection 4 continuous unlock failure
number of times.
R
SD10324 Connection 5 continuous unlock failure number of times This register stores the connection 5 continuous unlock failure
number of times.
R
SD10325 Connection 6 continuous unlock failure number of times This register stores the connection 6 continuous unlock failure
number of times.
R
SD10326 Connection 7 continuous unlock failure number of times This register stores the connection 7 continuous unlock failure
number of times.
R
SD10327 Connection 8 continuous unlock failure number of times This register stores the connection 8 continuous unlock failure
number of times.
R
SD10338 MELSOFT communication port (TCP/IP) continuous
unlock failure number of times
This register stores the MELSOFT communication port (TCP/IP)
continuous unlock failure number of times.
R
SD10340 MELSOFT direct connection continuous unlock failure
number of times
This register stores the MELSOFT direct connection continuous
unlock failure number of times.
R
SD10680 Open completion signal b0: Connection No.1
b1: Connection No.2
b2: Connection No.3
b3: Connection No.4
b4: Connection No.5
b5: Connection No.6
b6: Connection No.7
b7: Connection No.8
0: Close/Open not completed
1: Open completed
R
SD10681 Open request signal b0: Connection No.1
b1: Connection No.2
b2: Connection No.3
b3: Connection No.4
b4: Connection No.5
b5: Connection No.6
b6: Connection No.7
b7: Connection No.8
0: No open request
1: Open request exists
R
SD10682 Socket communications receive status signal b0: Connection No.1
b1: Connection No.2
b2: Connection No.3
b3: Connection No.4
b4: Connection No.5
b5: Connection No.6
b6: Connection No.7
b7: Connection No.8
0: No data received
1: Data receiving completed
R
SD10692 Predefined protocol ready 0:
1: Ready
R
SD10710 Predefined protocol setting data error information protocol
number
When a protocol setting data error is detected, stores the protocol
number where the error was detected.
R
SD10711 Predefined protocol setting data error information setting
type
0 is stored if an error is detected in the packet setting or element
setting.
1 is stored if an error is detected in the protocol detailed setting.
R
SD10712 Predefined protocol setting data error information packet
number
When an error is detected in the protocol setting data, stores the
packet number that detected the error.
R
SD10713 Predefined protocol setting data error information Element
number
When an error is detected in the protocol setting data, stores the
element number where the error was detected.
R
No. Name Description R/W
