Appendix 2 Special Register List
253
A
SD5082 Pulse width measurement falling ring counter value [Low-
order] (CH4)
This register stores the pulse width measurement falling ring
counter value (CH4).
R/W
SD5083 Pulse width measurement falling ring counter value [High-
order] (CH4)
SD5084 Pulse width measurement latest value [Low-order] (CH4) This register stores the pulse width measurement latest value
(CH4).
R/W
SD5085 Pulse width measurement latest value [High-order] (CH4)
SD5086 Pulse width measurement maximum value [Low-order]
(CH4)
This register stores the pulse width measurement maximum
value (CH4).
R/W
SD5087 Pulse width measurement maximum value [High-order]
(CH4)
SD5088 Pulse width measurement minimum value [Low-order]
(CH4)
This register stores the pulse width measurement minimum value
(CH4).
R/W
SD5089 Pulse width measurement minimum value [High-order]
(CH4)
SD5090 Pulse width measurement cycle latest value [Low-order]
(CH4)
This register stores the pulse width measurement cycle latest
value (CH4).
R/W
SD5091 Pulse width measurement cycle latest value [High-order]
(CH4)
SD5092 Pulse width measurement cycle maximum value [Low-
order] (CH4)
This register stores the pulse width measurement cycle maximum
value (CH4).
R/W
SD5093 Pulse width measurement cycle maximum value [High-
order] (CH4)
SD5094 Pulse width measurement cycle minimum value [Low-
order] (CH4)
This register stores the pulse width measurement cycle minimum
value (CH4).
R/W
SD5095 Pulse width measurement cycle minimum value [High-
order] (CH4)
SD5300 PWM pulse output number [Low-order] (CH1) This register stores the PWM pulse output number (CH1). R/W
SD5301 PWM pulse output number [High-order] (CH1)
SD5302 PWM pulse width [Low-order] (CH1) This register stores the PWM pulse width (CH1). R/W
SD5303 PWM pulse width [High-order] (CH1)
SD5304 PWM cycle [Low-order] (CH1) This register stores the PWM cycle (CH1). R/W
SD5305 PWM cycle [High-order] (CH1)
SD5306 PWM Number of output pulses current value monitor
[Low-order] (CH1)
This register stores the PWM pulse output number current value
(CH1).
R
SD5307 PWM Number of output pulses current value monitor
[High-order] (CH1)
SD5316 PWM pulse output number [Low-order] (CH2) This register stores the PWM pulse output number (CH2). R/W
SD5317 PWM pulse output number [High-order] (CH2)
SD5318 PWM pulse width [Low-order] (CH2) This register stores the PWM pulse width (CH2). R/W
SD5319 PWM pulse width [High-order] (CH2)
SD5320 PWM cycle [Low-order] (CH2) This register stores the PWM cycle (CH2). R/W
SD5321 PWM cycle [High-order] (CH2)
SD5322 PWM Number of output pulses current value monitor
[Low-order] (CH2)
This register stores the PWM pulse output number current value
(CH2).
R
SD5323 PWM Number of output pulses current value monitor
[High-order] (CH2)
SD5332 PWM pulse output number [Low-order] (CH3) This register stores the PWM pulse output number (CH3). R/W
SD5333 PWM pulse output number [High-order] (CH3)
SD5334 PWM pulse width [Low-order] (CH3) This register stores the PWM pulse width (CH3). R/W
SD5335 PWM pulse width [High-order] (CH3)
SD5336 PWM cycle [Low-order] (CH3) This register stores the PWM cycle (CH3). R/W
SD5337 PWM cycle [High-order] (CH3)
SD5338 PWM Number of output pulses current value monitor
[Low-order] (CH3)
This register stores the PWM pulse output number current value
(CH3).
R
SD5339 PWM Number of output pulses current value monitor
[High-order] (CH3)
No. Name Description R/W
